Product Hot And Cold Resistance Test Thermal Shock Chamber For Product Quality

Product Hot And Cold Resistance Test Thermal Shock Chamber For Product Quality

KOMEG Thermal Shock Chambers’ Characteristics

1. Insulation material: high-strength PU foam and high-density glass fiber cotton, the purpose is to ensure high accuracy and uniformity, to avoid unnecessary energy loss.

2. Large-size full-color LCD touch screen display, easy to operate, easy to edit the program. PID has automatic calculation function; self-diagnosis function, step by step display failure message and fault shooting solution.

3. An RS-232 and RS-485 communication interface, supporting the recorder, scalability and strong. We also support PC via wifi or line for remote control (recommended).

4. Interior and shell material:
Small standard models, the general use of stainless steel wall # 304 1.0mm, stainless steel shell # 304 1.2mm;
Larger models or some special needs custom, we use # 304 stainless steel inner wall 1.5 to 3.0mm, stainless steel # 304 shell over 1.5mm;

5. Inner box material for the SUS304 # installation of stainless steel imports, the outer box for the steel, paint the application of automotive coating technology. Box with triumph processing machine forming, beautiful appearance.

6. Frozen method: water or air-cooled

Standards

●  GB-2423.1-2008 (IEC68-2-1) Test A: Low Temperature Test

●  GB-2423．2-2008 (IEC68-2-2) Test B: High Temperature Test

●  GJB360．8-2009 (MIL-STD．202F) High Temperature Operating Life Test

●  GBJl50．3-2009 (MIL-STD-810D) High Temperature Test

●  GBJl50．4-2009 (MIL-STD-810D) Low Temperature Test

Differences

Zone 3 and Zone 2 Thermal shock chamber differences:

2 Zone Thermal Impact Chamber:
There are only two rooms: high temperature room and low temperature room
Advantages: short conversion time, the need for smaller space
Disadvantages: test sample movement. The size of the test sample is limited by the basket size

3 zone thermal shock room:
Three rooms in total: test space, high temperature. Room and low temperature
Advantages: The weight of the test sample is slightly limited, the test sample remains stationary, can reduce the impact of the sample on its movement can be used for load testing.
Compared with the 2 zone, the failure rate is relatively low, the cost is low.
Disadvantages: long conversion time

Specification

KTS Series
