Industrial Digital Display Heating Drying Usage Hot Air Circulation Oven
Industrial digital display heating drying usage hot air circulation oven
Application
Electric heat oventemperature up to 300°C, Thermostatic control with an accuracy of plus minus 2°C. Heating elements are provided at bottom only. stainless steel wall painted in epoxy powder coating with wire mesh shelves.To work on 220/3800 volts A. C. supplied with
specification
1.We are manufacturer,selling our produces.
2.Give you reasonable price.
3.Guaranteed goods high precision and stability
4. Provide our customers 1 year after sales service.
Features
1) Microcomputer electronic digital control, precision & reliability.
2) High temperature endurance & non-aging.
3) SUS#304 stainless steel inner chamber and excellent argon arc welding.
4) Forced circulation air, the temperature rise fast, even distribution.
5) PID control, double overheating protection, safety and reliability.
6) Two groups of moving plates can be adjusted height.
Technical parameter
| Specifications of drying oven | |||||
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 |
| Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 |
| Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | |||
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) | ||||
| Temp. constancy | ±1.0 ºC | ||||
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | ||||
| Heat up time | 50 ºC to 200 ºC within 50 min | ||||
| Interior material | Stainless steel plate | ||||
| Exterior material | Painted Stainless steel plate | ||||
| Insulation material | Glass wool | ||||
| Safety devices | No fuse breaker, over temp protection, ceramic fuse | ||||
| Accessories | Recorder, insolating layer | ||||
|
Note: 1. We reserve the right to change specifications without prior notice |
|||||
|
specifications
|
||||
|
Model
|
KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 |
| Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 |
| Capacity(KVA) | 6.5 | 7.5 | 8.5 |
9.5
|
| Power |
AC 380V±10% 3Φ4wire 50Hz/60Hz
|
|||
| Temp. range |
50 ºC~ 200 ºC( 300 ºC)
|
|||
| Temp. constancy |
±1.0 ºC
|
|||
| Temp. uniformity |
±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
|
|||
| Heat up time |
50 ºC to 200 ºC within 50 min
|
|||
| Interior material |
Stainless steel plate
|
|||
| Exterior material |
Painted Stainless steel plate
|
|||
| Insulation material |
Glass wool
|
|||
|
Safety devices
|
No fuse breaker, over temp protection, ceramic fuse | |||
|
Accessories
|
Recorder, insolating layer | |||
|
Note: 1. We reserve the right to change specifications without prior notice
|
||||
