1500 Controller LED Light Industrial Test Chamber , Temperature Humidity Test Chamber
1500 Controller Industrial LED Light Aging Test Equipment Temperature Humidity Test Chamber
Product Description
Temperature Humidity Test Chamber is mainly and widely used for various types of testings for material / product quality control, such as prototype evaluation, research & development testing, production quality control testing, accelerated aging testing, reliability testing, failure analysis, and any other application where environmental simulation is needed.
Application
Suitable for all kinds of electronic products,expecially for products with heating characteristics
Product and loading area should be separated
Large-scale production
Specifications
| Specifications | |
| Interior dimensions(W*H*D) mm | 1500*1280*550 |
| Exterior dimensions(W*H*D) mm | 1720*1980*750 |
| Temp. range | Room Temp. +20～+100℃ |
| Temp. constancy | ±0.5℃ |
| Temp. uniformity | ±3℃ |
| Test. capacity | 88PCS/CYCLE(Custom made available) |
| Dimension | 100W*100HJ*50D(MM) |
| Test range | FAN(full machines number) |
| Voltage range | 3～50V |
| Current range | ±5% |
| Speed | 0-15000RPM,±8% |
| The detection speed | 7-12sec/cycle |
|
Note: 1. We reserve the right to change specifications without prior notice |
|
Features
1. Standard combined design.
2. SUS#304 stainless steel,firm structure, waterproof design.
3. Suitable for test with large quantity and volume products.
4. Adopt imported large LCD Chinese/English microcomputer temperature controller, easy setting, strong function.
5. Standard RS-232C communication interface device.
6. Unique circulation duct design.
7. Comprehensive security control design, adopt intelligent PID+SST/SCR inverse two-way synchronous output,including the slope of the advanced control logic.
8. Heating box and explosion-proof heater design, advanced PID servo control, security, stability and reliability.
You are warmly welcomed to KOMEG.
We hope to be your reliable business partner in China.
For our new design can achieve high temp. Unifornity (± 0.5 C ).
Tecumseh or Danfoss compressor for your alternative choice.
Germany imported wall material make sure the reliability and good performace.
In addition to Programmable Temperature Humidity Chamber, we also produce:
1) Temperature/ humidity test series: Temperature humidity test chamber, Walk in environmental room, Thermal shock test chamber, High altitude low pressure simulation test chamber.
2) Aging test series: Hot air oven, Vacuum drying oven, Air ventilation aging test chamber, Steam aging test chamber, Ozone resistance test chamber, Burn in test equipment.
3) Weather simulation test series: Rain spray test chamber, dust test chamber, Xenon lamp aging test chamber, UV test chamber.
4) Mechanical test series: High frequency vibration test machine, drop test machine , Glue dispensing machine etc.
Q1: What is the Warranty?
Generally, 12 months warranty. But for drying oven, the warranty is 18 months. If any quality problems on our side occured in this period ,we will take on the cost of shipping and component parts.
Q2: What's the delivery term?
Usually, 20 - 25 days after order confirmation. It will be took more time for customization service. If you are in urgent need, we can make special arrangement for you. It could be shipped by sea, by air or by air express.
Q3: What’s the payment term?
Accept different kinds of payment terms, such T/T, L/C, Paypal.
Q4: Is it ok for customization service?
Of course you can. We are manufacturer of environmental test equipment. Once with your detailed requests, we could make environmental test chamber accordingly.
