Laboratory Vacuum Drying Equipment With Digital Display / Control CE Approved
Laboratory Vacuum Drying Equipment With Digital Display / Control CE Approved
Application
Lab vacuum oven have become very popular in recent times and specifically vacuum heat-treating is mandatory for parts that are manufactured without surface damage like oxidation. Rapid heating and cooling allows operators to quickly cycle through materials which greatly benefits the efficiency of the entire manufacturing process. By having absolute control of the temperature levels inside the vacuum oven then manufacturers can guarantee a higher level of quality assurance. The vacuum range is room pressure~-98Kpa, adjustable.
Key Specifications/Special Features:
-
Rated power: 2,200VA, ±10%
-
Temperature control range: 50 to 200℃
-
Temperature fluctuation: ±1℃
-
Vacuum degree: <133Pa
-
Operating room dimension: 56 x 60 x 64cm
-
Overall dimension: 72 x 82 x 175cm
-
Packing size: 89 x 92 x 193cm
-
Net/gross weight: 215/275kg
-
Application range:
- This type of product is suitable for research institutes, hospitals and mining industries.
- It specializes in the drying of heat-sensitive, easily oxidized and disintegrated substances, and can quickly dry product made of complex substances. The studio can be filled with noble gas
-
Structural characteristics
-
The microcomputer intelligent temperature controller is accurate and reliable
-
The heater controls temperature respectively is installed on the shelves in the dryer, it's heating takes less time and has a good uniformity
-
Studio is made of stainless steel plate and polished to ensure aesthetics and durability
-
The door is made of steel bulletproof double glass to ensure the safety of operator
-
The door seal is made of overall shape silicone rubber to ensure a high vacuum in the chamber. The tightness of the seal can be adjusted and the studio can be filled with noble gas
-
Vacuum uses microcomputer program to control digital display. The max program cycle can up to 99 times
-
Technical parameter
| Specifications of drying oven | |||||
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 |
| Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 |
| Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | |||
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) | ||||
| Temp. constancy | ±1.0 ºC | ||||
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | ||||
| Heat up time | 50 ºC to 200 ºC within 50 min | ||||
| Interior material | Stainless steel plate | ||||
| Exterior material | Painted Stainless steel plate | ||||
| Insulation material | Glass wool | ||||
| Safety devices | No fuse breaker, over temp protection, ceramic fuse | ||||
| Accessories | Recorder, insolating layer | ||||
|
Note: 1. We reserve the right to change specifications without prior notice |
|||||
|
specifications
|
||||
|
Model
|
KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 |
| Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 |
| Capacity(KVA) | 6.5 | 7.5 | 8.5 |
9.5
|
| Power |
AC 380V±10% 3Φ4wire 50Hz/60Hz
|
|||
| Temp. range |
50 ºC~ 200 ºC( 300 ºC)
|
|||
| Temp. constancy |
±1.0 ºC
|
|||
| Temp. uniformity |
±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
|
|||
| Heat up time |
50 ºC to 200 ºC within 50 min
|
|||
| Interior material |
Stainless steel plate
|
|||
| Exterior material |
Painted Stainless steel plate
|
|||
| Insulation material |
Glass wool
|
|||
|
Safety devices
|
No fuse breaker, over temp protection, ceramic fuse | |||
|
Accessories
|
Recorder, insolating layer | |||
|
Note: 1. We reserve the right to change specifications without prior notice
|
||||
