10800L Double door industrial drying oven 304 stainless steel vacuum drying Oven
10800L Double door 304 stainless steel industrial drying oven
Overview
Able to accurately simulate a wide range of complicated natural environments, and is suitable for
reliability test in industrial products. Meet GB5170.2.3.5.6-95 standard requirements of environmental
testing equipment and test methods.
Description
10800L walk in oven Inner chamber size: 2Wx1.8Hx3D m
Temp. Range:+60~+250℃ Power: AC 3 phase 380V, 50Hz, 100KW
Prouduct Specifications
| Product model | Drying oven YPO-10800 | Power supply | AC 3∮ 380V 50Hz 100KW |
| Inner size | 2(W) x1.8(H) x3(D) mm | ||
| External size | 2.7(W) x 2.2(H) x3.2(D) mm(approx.) | ||
|
Temp. range |
+60℃～+250 ℃ | ||
| Heating rate | 0~5℃/min from +60℃ to +250℃, adjustable | ||
| Cooling rate | 4℃/min from +250℃ to +60℃, through the air volume value to control the fresh air volume. | ||
| Temp. fluctuation | ±0.5℃ | Temperature uniformity | ±3℃ |
| Chamber material | 304 Stainless steel for inner chamber, cold rolled sheet with blue coating for external chamber | ||
| Insulation | Fiberglass wool | ||
| Controller | Temperature controller, digital set mode, digital display, PID auto calculation, SSR control. | ||
| Heating system |
Special design oval electric ceramic tile with Sweden-made electrical heater, low radiation, valid for 5 to 10 years’ use |
||
| Wind cycling system | Taiwan-made motor specially designed for hot ovens, together with centrifugal fan for uniform wind | ||
| Air ventilation system |
All in all out adjustable air throttle, directly connected with air exhaust duct |
||
| Door | Double door, explosion-proof lock, silicone gaskets | ||
| Standard accessories |
|
||
| Warranty | 12 months free parts warranty | ||
Features
● GB-2423．2-89(IEC68-2-2)Test B: High Temperature Test
● GJB360．8-87(MIL-STD．202F) High Temperature Life Test
● GBJl50．3(MIL-STD-810D) High Temperature Test
Display
Packing and Shipment:
1,Pre-sales service
Before the purchase, our company will provide customers with detailed product-related information, and
welcome you to visit the company and check the goods.
2,After-sales service
After the completion of the transaction, our company will be arranged different after-sales service
according to the ease of the goods , and even arrange work engineers on-site service.
3,Warranty period
Our product warranty is 12 months and we are committed to responding within 48 hours of the problem,
providing a solution.
