1394 L Left Open Industrial Drying Ovens , Laboratory Drying Oven Touch Panel Controller
1394 L Left Open Industrial Drying Ovens , Laboratory Drying Oven Touch Panel Controller
Product Overview
This series is applicable to the reliability test and production of industrial products, with the characteristics
of high temperature control accuracy and wide control range, performance index accords with
GB5170.2.3.5.6-95 "electrical and electronic products environmental testing equipment basic parameter
calibration method of high temperature test equipment” required standards.
Specifications
|
Air Circulation Mode |
Forced Air Circulation |
|
Temperature Range |
RT+20℃～300℃ |
|
Temperature Controller |
Imported microcomputer automatic calculus controller 4 digit LED display AUTO TURNING PID Control Into Force Optional ALARM or TIMER Function Selection Slope Control optional ℃ or ℉ optional SWITCHING POWER 85-265V AC |
|
Temperature Fluctuation |
±1℃ |
|
Temperature Uniformity |
±2.0℃(RT20～100℃) ±5.0℃(101～200℃) |
|
Temperature Sensing Element |
K thermocouple |
|
Material |
Inner Material: SUS ＃304 stainless steel, External Material: Cold stoving varnish |
|
Insulation Material |
Glass Wool |
|
Heating time |
RT20℃～300℃ within 65min |
|
Control Mode |
PID+SSR Output |
|
Packing |
silica gel |
|
Timer |
Controller possess timer function |
|
Accessory |
2.5 meter power line, backup fuse *1 |
|
Protector |
Over-temperature protector, motor overload protector, buzzer, trouble lamp, no-fuse switch. |
|
Heater Material |
Fins radiating tube type stainless Steel Electric Heater |
|
Samples Holder Material |
Galvanization Iron Grille Plate *2( 2 more pieces for free ) |
|
Workspace volume |
W 1200 × H 1320 × D 880 mm |
|
External Size |
W 1600 × H 2070 × D 1100 mm |
|
Electric Heater |
8.5 KW |
|
Door |
Left open |
|
Power |
AC380V±10%, 3 phase 4 wires + Ground Wires |
Features
GB-2423．2-89(IEC68-2-2)Test B: High Temperature Test
GJB360．8-87(MIL-STD．202F) High Temperature Life Test
GBJl50．3(MIL-STD-810D) High Temperature Test
Meaningful picture
Packing and Shipment:
1,Pre-sales service
Before the purchase, our company will provide customers with detailed product-related information, and
welcome you to visit the company and check the goods.
2,After-sales service
After the completion of the transaction, our company will be arranged different after-sales service
according to the ease of the goods , and even arrange work engineers on-site service.
3,Warranty period
Our product warranty is 12 months and we are committed to responding within 48 hours of the problem,
providing a solution.
