Product Description:
High-low temperature test chamber products simulate the temperature variation in the atmospheric environment. Mainly for electrical, electronic products, and its components and other materials in the high-temperature, low-temperature comprehensive environment transport, use the adaptability test. For product design, improvement, identification and testing and so on.
Product characteristics:
1:Built-in mobile wheels allow easy movement and placed, with a strong positioning screw position.
2: Compressor cycling system used France “Tecumseh” brand which can effectively remove condenser pipe and between capillary Lubricating oil and whole series adopt environmental protection refrigerant (R23, R404)
3: Interior material is high quality SUS304 stainless steel
4:Programmable color LCD touch screen controller
Parameter Specifications:
| Secifications ( at +20℃ room temp. Or+25℃ water temp with empty load) | |||||
| Model | KMH-L series | ||||
| KMH-150L | KMH-225L | KMH-408L | KMH-800L | KMH-1000L | |
| Interrior material(cm) | 60*60*46 | 70*70*48 | 70*75*80 | 100*100*80 | 100*100*100 |
| Exterrior material(cm) | 88*173*140 | 98*189*146 | 98*194*174 | 128*216*175 | 128*216*195 |
| Weight(Kg) | 250 | 300 | 420 | 530 | 600 |
| Equipment power(KW) | 7.5 | 7.5 | 8.5 | 14.5 | 14.5 |
| Tempeture range | -40 ℃ ～ +150 ℃ | ||||
| Humidity range | 20 ～ 98%R.H | ||||
| Tempeture constancy | ±0.5℃ | ||||
| Humidity constancy | ±2.5% R.H | ||||
| Tempeture uniformity | ±2.0 ℃ | ||||
| Humidity uniformity | ±3.0% R.H(＞75%) ±5.0% R.H (≤75%) | ||||
| Heating rate | -40℃～+100℃ Within 45 minutes | ||||
| Cooling rate | +20℃～-40℃ Within 60 minutes | ||||
| Controllor | Touch screen controller English menu Operation mode:setting or program | ||||
| Refrigeration system | Air cooled (Water Cooled Type is option) | ||||
| Hermetic compressor, stage refrigeration system | |||||
| Interior material | Stainless Steel Plate ( SUS 304 ) | ||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||
| System | Balanced & Humidity Control System | ||||
| Wiring method | AC 380±10 % 50Hz ,3 phase 4 wires +Ground Wires | ||||
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
|||||
Product Picture:
Certifications:
After-sale Service:
If there is a problem with the product test, we will reply 24 hours and propose a solution within three days.Customer needs to be met on siteFreight, travel expenses must be borne by the customer
