China Walk - In Stability Chamber For Computer Telecommunication Systems Rapid Change Temp for sale

Walk - In Stability Chamber For Computer Telecommunication Systems Rapid Change Temp

Price Negotiable

Price: Negotiation

MOQ: 1pcs

Delivery Time: 35 days after confirm the order

Brand: Komeg

Product Description

Walk-in Stability Chamber For Computer Telecommunication Systems Rapid Change Temp

More information , pls kindly contact :anna@komegtech.com ,Whatsapp :+86-18098281986

Technical Specification

Model	KMHW-14.4CBM
Volume(m³)	14.4 CBM
Interior Dimensions	W2100 x H2100 x D2050mm
Exterior Dimensions	W3250 x H2350 x D2250mm
Safety Devices(standard)	No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection
Standard accessories	Sight window1, cable port ( portΦ50mm ) 1, chamber lamp*1, status indicator
Control System	Balanced Temperature & Humidity Control System
Refrigeration system	Water Cooled Semi-hermetic compressor, single stage or cascade refrigeration system, CFC free refrigerant ( HFC-507 and HFC-23 )
Heating up& Cooling down rate	10ºC/per min
Temp. range	Maximum: 80 ºC,120 ºC; Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC
Humidity Range	10%, 20%, 30% ~ 95%
Temp. constancy	±0.5 ºC
Humidity constancy	±2.5%R.H
Temp. uniformity	±2.0 ºC
Humidity uniformity	±5.0%R.H

Chamber structure

Insulation material	Glass wool
Heater	High quality nickel-chromium alloy wire electric heaters
Temperature Controller	ST-570 South Korea imported thermostat ST-570 high precision(0.1%), high performance Support multiple input (T / C, RTD, DCV) Can finish multiple output and simultaneous output (Max 4 points) Simple parameter operation , available text settings Supports suppressing system Overshoot function Alarm output 1 point Auxiliary output status operation screen displayed Each zone input adjustment function (Max 4 Zone) To achieve control heating and cooling function PID automatic adjustment function (AT Gain) (AT Gain) Supports multiple communication protocols (Modbus, etc.) To achieve high quality, high reliability (CE, CUL, ISO, etc.)
Temperature body	K thermoelectric
ventilator	Ventilator 1 type, displacement of 130 ~ 250m3 / h (from the exhaust fan to the duct outside the laboratory to be handled by the customer)
Protection System	Over-temperature protection, motor overload protection, buzzer, fault indicator, no fuse switch.

OEM& ODM are welcome

Description

ut Car Part Walk-in Stability Chamber,Humidity Chambe

Air-evaporator system for low-performance chambers operating at fixed climatic parameters;
Reach-in system with external air treatment for standard climatic cycles;
System with internal air treatment for high performances (fast cycles);

Application

Suitable for all kinds of electronic products,expecially for products with heating characteristics
Product and loading area should be separated Large-scale production .

Feature

Design a comprehensive security control: adopt intelligent PID + SST/SCR is reverse the two way synchronization output, including the slope of the advanced control logic.
The use of the imported large LCD display Chinese/English microcomputer controller, set the simple, strong function effect.
A standard RS-232C communication interface devices.
Flexible fixturing able to handle most device types.
Modular construction enables easy maintenance.
High quality instrumentation can be swapped out for periodic re-calibration.
Accurate temperature control, high precision.
