400CFM 14.5 Bar Small Portable Screw Air Compressor KSCY-400/14.5 For Borehole Drilling
400CFM 14.5 Bar Small Portable Screw Air Compressor KSCY-400/14.5 For Borehole Drilling
KSCY-400/14.5 400CFM 14.5bar diesel mobile air compressor
The performance of screw air compressor:
1. High reliability, few parts and no wearing parts, so it operates reliably and has a long service life. Generally, the design life of the main screw machine head is 30 years.
2. It is easy to operate and maintain, with a high degree of automation, and operators do not need to undergo long-term professional training to achieve unattended operation.
3. The power balance is good, there is no unbalanced inertial force, the machine can work smoothly at high speed, and realize the operation without foundation.
4. Strong adaptability, with the characteristics of forced gas transmission, the volume flow is almost not affected by the exhaust pressure, and can maintain high efficiency in a wide range of working conditions, without making any changes to the compressor structure, It is suitable for a variety of working conditions, so it is easy to finalize mass production.
5. In multi-phase mixed transmission, there is actually a gap between the rotor tooth surfaces, so it can withstand liquid impact, and can be pressurized to send gas containing liquid, gas containing dust, gas that is easy to polymerize, etc.
6. The flow rate of the slide valve is adjusted without the need for backflow, which can effectively reduce energy consumption.
Technical Parameters
| Model | Working pressure (Bar) |
Capacity (CFM) |
Connector |
Weight (kg) |
Dimension (mm) |
| KSCY-220/8 | 8 | 220 |
G1 1/4 X 1, G3/4 X 1 |
1400 | 3030X1840X1580 |
| KSCY-330/8 | 8 | 330 | 1550 | 3240X1760X1785 | |
| KSCY-425/10 | 10 | 425 | 1880 | 3300X1880X2100 | |
| KSCY-400/14.5 | 14.5 | 400 | 1880 | 3300X1880X2100 | |
| KSCY-550/13 | 13 | 550 |
G1 1/2 X 1, G3/4 X 1 |
2400 | 3000X1520X2200 |
| KSCY-550/14.5 | 14.5 | 550 | 2600 | 3000X1520X2200 | |
| KSCY-560/15 | 15 | 560 | 3200 | 3600X1800X2450 | |
| KSCY570/12-550/15 | 12/15 | 570/550 | 3200 | 3600X1800X2450 | |
| KSCY-680/14.5 | 14.5 | 680 | 3200 | 3600X1800X2450 | |
| KSCY650/20-700/17 | 20/17 | 650/700 | 3200 | 3600X1800X2450 | |
| KSCY-750/20 | 20 | 750 | 3200 | 3600X1800X2450 |
