Portable Crawler Drilling Rig Machine Rotary Drilling Rig For Water Well
Silk 2016 KY100 portable crawler drilling rig for water well
What's the feature of our product KY100?
Powerful and Reliable Engine
1. Adopt famous 2-cylinder diesel engine as driving force which has advantages of large power, powerful grade-ability, small vibration and reliable operation.
2. Adopt patent diesel engine air inlet regulating device (Patent No. : 200820087606.3) and desert air filter two-stage filter. That strengthens the crawler rock drill’s adaptability to severe environment and lengthened the diesel engine’s service life.
Adjustable Boom
Reliable Hydraulic Pump System
1. Oil supplied by two independent gear pumps, reliable operation, strong adaptability, easy maintenance.
2. Adopt gear transmission and soft connection, possessing compact structure and stable operation.
Reliable Hydraulic System
1. Adopt special hydraulic components. That improves the system’s stability and reliability.
2. Install oil liquid cooling device eliminatting the exothermic hydraulic oil’s influence on the system
What's the details of KY100?
Photoes 100% taken from factory
Specification of KY100
| KY100 | KY100 | KY100J |
| Rock Rigidity | F=6-20 | F=6-20 |
| Drilling Hole Diameter | 80-105mm | 80-105mm |
| Drilling Depth | 20m | 20m |
| Traveling Speed | 0-2km/h | 0-2km/h |
| Rotation Speed | 0-65r/min | 0-65r/min |
| Rotation Torque | 980N.m | 980N.m |
| Ma Feed Force | 15000N | 15000N |
| Push Way | Cylinder.Chain | Cylinder.Chain |
| Feed Stroke | 2000mm | 2000mm |
| Climb Capacity | 30 | 30 |
| Ground Clearance | 254mm | 254mm |
| Weight | 3200kg | 3200kg |
| Dimension | 4100*2030*2020mm | 4100*2030*2020mm |
| Guide Tilt | 23.5up,118.5down | 23.5up,118.5down |
| Guide Swing | 11.5right,36.5left | 11.5right,36.5left |
| Compensation Stroke | 900mm | 900mm |
| Boom Lift | up25-60 | up35-60 |
| Engine Model | YC2108 | ZS1125GM |
| Power | 33kw | 20.5kw |
| Working Pressure | 7-14bar | 7-14bar |
| Air Consumption | ≥10m3/min | ≥10m3/min |
| Components | Standard | Standard |
| Hammer | QCZJ90 | QCZJ90 |
| Rod | φ60*2000mm | φ60*2000mm |
| Bit | φ90 | φ90 |
| Air Hose | φ38*8*20 | φ38*8*20 |
| recommended Air compressor | LGCY-10/7 | LGCY-10/7 |
Which compressor should i buy for the KY100 drilling rig?
Recommand screw air compressor LGCY-12/10 for 2014 Special Price mines rock drilling rigs KY100 with ISO,GC,GHOST certificate
Do you supply spare parts for the machine ?
We supply every spare parts of our machine,contact us for more detials.
How can i do if the machine is break down in foreign countries?
First, take easy my friend,then contact us,if possible we will send our technican by rocket, but the cost is too much,we will send our techinican by plane within 48 hours.
