Refrigeration Piston Compressor CSH8573-140-40P 140hp High Peripheral Speed

Price Negotiable

Price: Disscussed

MOQ: 1

Delivery Time: 7 days

Product Description

1. Product introduction

Flexible

Dual capacity control: switch between 4-stage and seamless capacity control – with no compressor adaptation work
Suction and pressure connectors can be rotated in 90° increments

High efficiency profile outstandingly efficient thanks to

Advanced geometry
High rigidity
Patented production process for maximum precision
High peripheral speed

2. Product parameter(Specification)

screw compressor
Model	CFH Displ 60 HZ	Motor HP
CSH6553-50	165	50
CSH6563-60	205	60
CSH7553-70	238	70
CSH7563-80	274	80
CSH7573-90	311	90
CSH8553-110	380	110
CSH8563-125	433	125
CSH8573-140	495	140
CSH9553-180	645	180
CSH9563-210	742	210
CSH9573-240	844	240
CSH9583-280	971	280
CSH9593-300	1098	300

3.Production details

	SI	IP
Displacement(2900 RPM 50 HZ)	410 m³/h	14488 CFH
Displacement(3500 RPM 60 HZ)	495 m³/h	17491 CFH
Weight	870 kg	1918 lb
Max,pressure(LP/HP)	19/28 bar	275/400 psi
Connection suction line	DN 100	4 1/8”
Connection discharge line	76mm-3 1/8”	76mm-3 1/8”
Motor Voltage(more on request)	380-415V PW-3-50HZ	440-480V PW-3-60HZ UL
Max operating current	246.0 A	246.0 A
Winding Radio	50/50	50/50
Starting current (Rotor locked)	665.0 A D/1023.0 A DD	716.0 A D/1036.0 A DD

4.Shipping, Payment,Delivery and Packing

1) .Shipping:

1. For Sample order in stock, we aim to ship the compressor within 3 days.

2. For any Bulk order, generally we ship compressor in 10-15 working days after receiving deposit.

2) .Payment:

1. T/T

2. Western Union

3) .Delivery:

Here we guarantee on time delivery and if necessary, we will provide you the best logistics solution for the goods to reach at your location on time.

4) .Packing:

Every products will be in carefully inspection for many times before Packing. Depending on the size and contents of your goods, we generally use different size of wooden box of package to secure goods.
