SAER Large Format Impresora 3200mm 4pcs & 8pcs i3200A1 Print Head Digital Fabric Plotter
Price:
Negotiation
MOQ:
1 set
Delivery Time:
15 work days
Brand:
SAER
Product Description
SAER Large Format Impresora 3200mm 4pcs & 8pcs i3200A1 Print Head Digital Fabric Plotter
Product Overview
Advanced digital fabric printing system designed for textile factories, featuring environmentally friendly operation and high-performance i3200 print heads.
Technical Specifications
| Model Type | CSR3200 |
| Print Head | 4 pieces i3200A1 |
| Ink Types | Sublimation ink, pigment ink |
| Number of Nozzles | (400 nozzles × 8 lines) × 4 heads |
| Color Configuration | Dual CMYK |
| Print Head Height | 1.5mm/6mm (adjustable) |
| Ink Supply Mode | Continuous ink supply |
| Max Materials Width | 3300mm |
| Max Printing Width | 3200mm |
| Roll Outer Diameter | 3 inch |
| Maximum Roll Weight | 100kg |
| Interface | USB 2.0 |
| RAM | 128M |
| Printer Power | AC380V, 50/60HZ |
| Power Consumption | Heater: 3KW, Printer: 4KW |
| Operating Temperature | 30-32℃ |
| Operating Humidity | 40-60% (Non-condensing) |
Printing Speed & Resolution
| Resolution (dpi) | Speed |
|---|---|
| 720×1200 dpi (4 pass) | 78 m²/h |
| 720×2400 dpi (8 pass) | 52 m²/h |
| 360×1200 dpi (2 pass) | 136 m²/h |
Key Features
Guide Rail: HIWIN mute guide rail with Germany IGUS silent drag chain for quiet printing environment.
Print Head: Four i3200A1 print heads for faster speed and longer lifespan. Feather printing function, easy correction and counterpoint. Intelligent cleaning system.
Axis System: X and Y axis equipped with AC servo motors for precision movement.
System Advantages
- Smooth fabric take-up and feeding operation
- Inflatable take-up and feeding rollers
- Unique filtering lampblack system for clean picture quality
- Feeding motor with positive and negative transfer function
- Constant tension transmission system
Application Industries
- Clothing industry: sample printing and character pattern color printing
- Personality printing: shops, cell phone decoration, gift shops
- Studio: digital image production
- Advertising industry: indoor and outdoor advertising
- Product proofing: traditional printing sample production
Professional Services
Logistics Service
Frequently Asked Questions
How can I place an order? Contact us with your order details, we will prepare the Proforma Invoice.
How can I pay? We accept T/T and Western Union payments.
Do you supply ink and materials? Yes, we recommend using original ink for optimal printer maintenance and can supply related materials.
Can you help with business setup? Yes, we can provide project ideas based on your product requirements and business goals.
What is the after-sale service? 12-month machine guarantee (print heads excluded). Online technical support even after guarantee period.
