Incoloy 800 WPNIC , Incoloy 825 WPNICMC Stainless Steel Stub Ends 6” SCH40S

Name: Incoloy 800 WPNIC , Incoloy 825 WPNICMC Stainless Steel Stub Ends 6u201d SCH40S
Brand: TOBO STEEL GROUP CHINA

Price Negotiable

Price: USD0.3-50 PER PC

MOQ: 2PCS

Delivery Time: 15DAYS

Brand: TOBO

Product Description

Incoloy 800 WPNIC , Incoloy 825 WPNICMC , Stainless Steel Stub Ends Lap Joint Stub End 6” SCH40S

Type

Stainless steel Stub ends.

Standard

ASME/ANSI B16.9 MSS SP-43

Size

1/2’’~48’’(Seamless);16’’~72’’(Welded)

Wall thickness

Sch5~Sch160XXS

Manufacturing process

Push, Press, Forge, Cast, etc.

Material

Carbon steel, stainless steel, alloy steel, duplex stainless, nickel alloy steel

Trade Name	INCOLOY® 800	INCOLOY® 800H	INCOLOY® 800HT	INCOLOY® 825
UNS #	N08800	N08810	N08811	N08825
Seamless Pipe / Tube	B/SB407 A/SA312 B/SB163 A/SA213	B/SB407 A/SA312 B/SB163 A/SA213	B/SB407 A/SA312 B/SB163 A/SA213	B/SB423 B/SB163
Welded Pipe / Tube	B/SB515 B/SB514 A/SA312/ A/SA358	B/SB515 B/SB514 A/SA312/ A/SA358	B/SB515 A/SA312	B/SB705 B474 B/SB704
Buttweld Fittings*	B/SB366 Grade WPNIC	B/SB366 Grade WPNIC10	B/SB366 Grade WPNIC11	B/SB366 Grade WPNICMC
Forged Valves	B/SB564	B/SB564	B/SB564	B/SB564 B/SB425 BAR
Forged Fittings	B/SB564	B/SB564	B/SB564	B/SB564
Flanges	B/SB564	B/SB564	B/SB564	B/SB564
Plate	B/SB409 A/SA240	B/SB409 A/SA240	B/SB409 A/SA240	B/SB424

Cast Steel Valves	A/SA351 UNS N08151	A/SA351 UNS N08151	-----	A/SA494 UNS N08826
Grade	CT15C	CT15C	-----	CU5MCuC
* The Following must be included with the ASTM designation and graded for the description to be complete: WP (S) = Seamless WP (W) = Welded WP (WX) = Welded with 100% x-ray WP (U) = Welded with 100% Ultrasonic examination CR = Corrosion resistant in acordance with MSS SP-43
