Butt Weld Pipe Cap Stainless Steel Pipe Cap Incoloy 800 / WPNIC , Incoloy 825 / WPNICMC

Price Negotiable

Price: USD0.3-50 PER PC

MOQ: 3PCS

Delivery Time: 15DAYS

Brand: TOBO

Product Description

WP347 / 317L / WPS31254 Stainless steel Cap 8” Sch80S Pipe end Cap Asme B16.9

Stainless Steel Pipe End Caps,

Chemical Analysis of ALLOY 825 (UNS N08825)
Common Names : Incoloy 825®, Nickelvac® 825, Nicrofer® 4221

Cb Ta

Other

.05 max

1.0 max

.03 max

.5 max

19.5 – 23.5

38.0 – 46.0

2.5 – 3.5

1.5 – 3.0

0.6 1.2

0.2 max

22.0 min

Specifications

Sheet/Plate	Round Bar	Pipe	Tube	Fittings	Forgings
ASME SB-424	ASME SB-425	ASME SB-423 ASME SB-829 ASME SB-705 ASME SB-775	ASME SB-163 ASME SB-704 ASME SB-751	ASME SB-366	ASME SB-564

Inconel Buttweld Fittings are available in different grades of the super alloy, as follows:

Grade	UNS	W.Nr.	Trade Name
Inconel 600	N06600	2.4816	Inconel 600®, Nickelvac® 600, Ferrochronin® 600
Inconel 601	N06601	2.4851	Inconel 601®, Pyromet® 601, Nicrofer® 601
Inconel 617®	N06617	2.4663	Inconel 617®, Nicrofer® 617
Inconel 625	N06625	2.4856	Inconel 625®, Chornin® 625, Altemp® 625, Nickelvac® 625, Haynes® 625 Nicrofer® 6020
Inconel	N07718	2.4668	Inconel 718®, Nicrofer® 5219, Alvac® 718, Haynes® 718, Altemp® 718
Inconel X 750	N07750	2.4669	Inconel X750®, Haynes X750®, Pyromet® X750, Nickelvac®X750, Nicorros® 7016
Incoloy 800	N08800	1.4876	Incoloy 800®, Ferrochronin® 800, Nickelvac® 800, Nicrofer® 3220
Incoloy 800H	N08810	1.4876	Incoloy 800H®, Ferrochronin® 800, Nickelvac® 800, Nicrofer® 3220
Incoloy 800HT	N08811	1.4876	Incoloy 800HT®, Ferrochronin® 800, Nickelvac® 800, Nicrofer® 3220
Incoloy 825	N08825	2.4858	Incoloy 825®, Nickelvac® 825, Nicrofer 4241®

Product name : stainless steel pipe cap

Item : buttweld-Cap

Details :

Pipe Cap Nominal Diameter		Pipe Cap Outside Diameter at Bevel		Pipe Cap Back to End
DN	NPS	Series A	Series B	E	T	E1
15	1/2	21.3	18	25	4.57	25
20	3/4	26.9	25	25	3.81	25
25	1	33.7	32	38	4.57	38
32	1.1/4	42.4	38	38	4.83	38
40	1.1/2	48.3	45	38	5.08	38
50	2	60.3	57	38	5.59	44
65	2.1/2	76.1(73)	76	38	7.11	51
80	3	88.9	89	51	7.62	64
90	3.1/2	101.6	-	64	8.13	76
100	4	114.3	108	64	8.64	76
125	5	139.7	133	76	9.65	89
150	6	168.3	159	89	10.92	102
200	8	219.1	219	102	12.70	127
250	10	273.0	273	127	12.70	152
300	12	323.9	325	152	12.70	178
350	14	355.6	377	165	12.70	191
400	16	406.4	426	178	12.70	203
450	18	457.2	478	203	12.70	229
500	20	508.0	529	229	12.70	254
550	22	559	-	254	12.70	254
600	24	610	630	267	12.70	305
650	26	660	-	267	-	-
700	28	711	720	267	-	-
750	30	762	-	267	-	-
800	32	813	820	267	-	-
850	34	864	-	267	-	-
900	36	914	920	267	-	-
950	38	965	-	305	-	-
1000	40	1016	1020	305	-	-
1050	42	1067	-	305	-	-
1100	44	1118	1120	343	-	-
1150	46	1168	-	343	-	-
1200	48	1220	1220	343	-	-
PS: When T is less the dimension in parentheses, the height E is available. Otherwise E1 is available.
