Tube Reducer Butt Weld Fittings Nickel 200 UNS N02200 Nickel 99.2 SCH10S To SCH80S
Nickel 200 UNS N02200 Nickel 99.2 But Weld Fittings Elbow Tee Reducer 1” To 24” SCH10S To SCH80S ASME B16.9
Nickel 200 (UNS N02200)
General Description
Nickel 200 ( UNS N02200) , a grade of pure nickel contains 99.2% nickel, has excellent mechanical properties, magnetic properties, high thermal, electrical conductivity and excellent resistance to many corrosive environment. Nickel 200 is useful in any environment below 600℉(315℃). It has highly resistance to neutral and alkaline salt solutions. Nickel 200 also has low corrosion rates in neutral and distilled water.
The applications of pure nickel includes food processing equipment, magnetostrictive devices and rechargeable batteries, computers, cellular Phone, power tools, camcorders and so on.
Chemical Composition
| Alloy |
Ni% |
Mn% |
Fe% |
Si% |
Cu% |
C% |
S% |
| Nickel 200 | Min 99.2 | Max 0.35 | Max 0.4 | Max 0.35 | Max 0.25 | Max 0.15 | Max 0.01 |
Physical Data
| Density | 8.89g/cm3 |
| Specific Heat | 0.109(456 J/kg.℃) |
| Electrical Resistivity | 0.096×10-6ohm.m |
| Melting Point | 1435-1446℃ |
| Thermal Conductivity | 70.2 W/m-K |
| Mean Coeff Thermal Expansion | 13.3×10-6m/m.℃ |
Typical Mechanical Properties
| Mechanical Property |
Nickel 200 |
| Tensile Strength |
462 Mpa |
| Yield Strength |
148 Mpa |
| Elongation |
47 |
