1.4835 Stainless Steel Seamless Pipe / Tube For Fluid , Annealed And Pickled
1.4835 Stainless Steel Seamless Pipe / Tube For Fluid, Annealed And Pickled
Quick Detail:
1.Material: TP304/304L,TP316/316L,TP304H,TP347H, TP317/317L ETC
2.O.D: 6mm-830mm , Thickness:0.6-60mm
3.Surface: Solid Annealed / Pickling / 180# 240# 320# 400#
4.Certificate: PED, GOST, GB/T19001-2000, ISO
|
Name |
Stainless Steel seamless Pipe |
|
Standard |
EN10216-5 , EN10216-2,DIN 17456 , DIN 17458,ASTM A312, |
|
Material Grade |
TP304/304L,TP316/316L,TP347/347H, TP321/321H, TP310/310S,TP317/317L |
|
TP410 TP410S TP403 |
|
|
S31803,S32205,S32750 |
|
|
Diameter |
OD: 6-830mm |
|
W.T: 0.6mm - 60mm |
|
|
Length |
Up to 13 meter or as customers' request |
|
Tolerance |
According to the Standard. |
|
Surface |
Natural Color of annealing & pickling, 180G, 320G, 400G Satin / Hairline |
|
400G, 500G, 600G or 800G Mirror finish |
|
|
Test |
UT, ET, HT, RT,ect, and others according to the standard, |
Stainless Steel Seamless Pipe:
1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include “Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of
the bundle is plastic woven bag, or Plastic film.
7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
8.MTC: BWSS Official Original MTC paper will be supplied for each order.
OUR TOBO GROUPThe ety in production, quality first.
Specialized production workshop, professional production staff.
Shop the '7 s' principle
The standardized production, the comprehensive treatment
TOBO GROUP
Make development by enlarging scale brand building and internationalization.
Keep Challenging and Innovation.
Advance manufacturing instruments.
Create perfect quality.
Take strict testing as guarantee, upgrade grade as object.
EXHIBITION AND CUSTORMER SATISFACTORY
APPLICATIONS FIELD :
|
ndustry |
Applications |
Industry |
Applications |
|
Chemical |
Heat Exchanger,Boiler |
Sugar |
Evaporators, Condensers, Driers |
|
Petrochemicals |
Condensers |
Automobiles |
Muffler Tubes Hydraulic Tubing |
|
Refineries |
General Piping |
Construction |
Architectural Furniture |
|
Fertilizers |
Pressure Vessels |
Pharmaceuticals, Dairy, Food & Beverages |
Machineries Process Piping |
|
Paper & Pulp |
Industrial Equipments |
Submersible Pumps |
Pump Casing Applications |
|
Engineering |
Machineries Instrumentation Tubing |
|
Quick Details
| Standard: |
JIS, AISI, ASTM,
GB, DIN, EN
|
Place of Origin: |
Shanghai, China
(Mainland)
|
Brand Name: | TOBO |
| Type: |
Seamless
|
Steel Grade: |
300 Series
|
Application: |
Fluid pipe,
Structure
Pipe,Oil pipe,,
Boiler tube,
Heat exchanger tube
|
| Certification: |
PED,ISO9001-2008
|
Thickness: |
0.5-100mm
|
Outer Diameter: |
6-813mm
|
| FINISH: |
Annealed & Pickled,
Bright Annealing,
Polished
|
Process: |
Cold Drawn,
Cold Rolled,
Precision Cold Rolled
|
Specification: |
ASTM A312
|
| Material: |
UNS S30815/253MA
|
Packaging & Delivery
| Packaging Details: |
Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested. |
| Delivery Detail: | 30 Days |
Specifications
100% PMI, Spectro Chemical Aanlysis Test for Raw Material;100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test;
Product Name: 1.4835 stainless steel seamless pipe/tube
Standard: ASTM A269/ASME SA269 , ASTM A213 /ASME SA 213, A312, A511, A789, A790, A376, EN 10216-5, EN 10297,DIN 17456, DIN 17458, GOST 9941, GOST 9940, JIS G3446 JIS G3447 JISG3448 JIS G3459 JIS G3463 JIS G 3468
Material:
UNS S30815/253Ma, TP304/304L/304H, 316/316L, 321/321H, 317/317L, 347/347H, 309S, 310S,S31803,S32205, S2570,S32760,S32304, 904L
08X18H10 03X18H11 08X18H10T 12X18H10T 08X17H14M2 03X17H14M2 10X17H13M2T 20X23H18
SUS304TP SUS304LTP SUS304HTP SUS316TP SUS316LTP SUS316HTP, SUS321TP, SUS321HTP, SUS347TP, SUS347HTP, SUS310STP SUS317TP, SUS890LTP,
EN1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571, 1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845.
Nominal Dia: 1/2 "to 32" NB for seamless pipe
Schedules: 5S, 10S, 40S, 80S, 10, 20, 30...120, 140, 160, XXS
All dimensions are in accordance with ANSI B36.19 and ANSI B36.10
Size Range for tubing: OD:1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5"(12mm)
Length:
30 m(Max) or as your requirement
Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Finish: Annealed & pickled, bright annealing, polished
Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end
