Nickel Copper Alloy UNS NO4400 Based ASTM B164 Seamless Steel Tube
Nickel copper alloy UNS NO4400 based ASTM B164 Seamless Steel Tube
Quick Details
| Place of Origin: |
Shanghai, China (Mainland)
|
Type: |
Nickel pipe
|
Application: |
Ocean,Chemistry,Aviation,Rocket,Nuclear Reaction,Petrochemical so on, Ocean,Chemistry,Aviation,Rocket,Nuclear Reaction,Petrochemical so on
|
| Grade: |
alloy 400
|
Ni (Min): |
63 %
|
Powder Or Not: |
Not Powder
|
| Ultimate Strength (≥ MPa): |
483
|
Elongation (≥ %): |
35 %
|
Model Number: |
alloy 400
|
| Brand Name: | TOBO | Item: |
Super Alloy
|
Material: |
Nickel Base alloy
|
| Form: |
Can be customized
|
Surface: |
Polished
|
Certification: |
ISO9001:2008
|
| Superiority: |
super corrosion resistance / super high temperature
|
OEM: |
Yes,we are factory
|
Port: |
Shanghai
|
Packaging & Delivery
| Packaging Details: | In wooden box. |
| Delivery Detail: | Normally within 30 days. |
Monel 400
400 is copper nickel alloy,has good corrosion resistance. In salty water or seawater has excellent resistance to pitting corrosion, stress corrosion ability. Especially hydrofluoric acid resistance and resistance to the hydrochloric acid. Widely used in the chemical, oil, Marine industry.
It is widely used on many aspects,like valve and pump parts, electronic components, chemical processing equipment, gasoline and freshwater tanks, petroleum processing equipment, propeller shafts, marine fixtures and fasteners,boiler feedwater heaters and other heat exchangers.
Monel 400 International brand:
| USA | GE | UK | FR | |
| UNS | SEW VDIUV | BS | AFNOR | |
| Monel 400 | N04400 | W.Nr.2.4360 NiCu30Fe | NA 12 | Nu 30 |
Chemical Composition:
| Grade | Ni% | Cu% | Fe% | Mn% | C% | Si% | S% |
| Monel 400 | Min 63 | 28-34 | Max 2.5 | Max 2.0 | Max 0.3 | Max 0.5 | Max 0.024 |
Physical Properties:
| Grade | Density | Melting Point |
| Monel 400 | 8.83 g/cm3 | 1300°C-1390°C |
Mechanical Properties:
| Alloy | Tensile Strength (Rm N/mm2) | Yield strength (RP0.2N/mm2) | Elongation (A5 %) | HB |
| Monel400 | 480 | 170 | 35 | ≥331 |
Production Standard:
|
|
tube | Forging | Pipe | Sheet/Strip | Welding Wire |
| Standard | ASTM B164 | ASTM B564 | ASTM B165 | ASTM B127 | ERNiCu-7ERNiCu-7 |
Specifications
MONELalloy 400 is designated as UNS N04400 and Werkstoff Nr. 2.4360. It is listed in NACE MR-01-75 for oil and gas service.
Specifications for Alloy 400 include the following:
Bar,Rod,Wire, & Forgings: ASTM B564,ASTM B164.
Plate, Sheet & Strip: ASTM B127.
Pipe and Tube: ASTM B165, ASTM B163.
Fittings: ASTM B366 WPN
Chemical Composition
Nickel (plus Cobalt) .....................................................63.0 min.
Carbon..........................................................................0.3 max.
Manganese ...................................................................2.0 max.
Iron................................................................................2.5 max.
Sulfur ........................................................................0.024 max.
