ASTM A387 Gr.22L Alloy Steel Plate Length 0-12m Hot / Cold Rolled
ASTM A387 Gr.22L Alloy Steel Plate Length 0-12m Hot / Cold Rolled
Quick Details
- Standard: AISI, ASTM
- Grade: ASTM A387
- Thickness: 0.3~100mm or as per the customers' requirements
- Place of Origin: China
- Brand Name: TOBO
- Model Number: ASTM A387 Gr.22L alloy steel plate
- Type: Steel Plate
- Technique: hot/cold rolled
- Surface Treatment:BA,2B,Hairline,NO.1,NO.4,Mirror Finish
- Application: pressure vessel plate
- Special Use: High-strength Steel Plate
- Width: 0~2500mm or as per the custsomers'requirements
- Length: 0~12m or as per the customers' requirements
- Type1: ASTM A387 ASME SA387 Gr.2 pressure vessel alloy steel plate
- Type2: ASTM A387 ASME SA387 Gr.5 pressure vessel alloy steel plate
- Type3: ASTM A387 ASME SA387 Gr.9 pressure vessel alloy steel plate
- Type4: ASTM A387 ASME SA387 Gr.11 pressure vessel alloy steel plate
- Type5: ASTM A387 ASME SA387 Gr.91 pressure vessel alloy steel plate
- Type6: ASTM A387 ASME SA387 Gr.911 pressure vessel alloy steel plate
- Type7: ASTM A387 ASME SA387 Gr.12 pressure vessel alloy steel plate
- Type8: ASTM A387 ASME SA387 Gr.22 pressure vessel alloy steel plate
- Type9: ASTM A387 ASME SA387 Gr.22L pressure vessel alloy steel plate
| ASTM/ ASME | EN 10028-2 | BS 1501 | DIN 17175 | C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V | Y.S.(N/mm²) | T.S.(N/mm²) |
|
A285-C /A516-55 |
P235GH | 161-360A | H1 | 0.16 | 0.35 | 0.4/ 1.2 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 235 | 360/ 480 |
| A516-60 | P265GH | 161-430A | H11 | 0.2 | 0.4 | 0.5/ 1.40 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 265 | 410/ 530 |
| - | - |
223-490 A/B |
- | 0.2 | 0.4 | 0.5/ 1.40 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 265 | 410/ 530 |
| A516-65 | P295GH |
224-460 A/B |
17Mn4 | 0.08/ 0.20 | 0.4 | 0.9 / 1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 295 | 460/ 580 |
| A516-70 | P355GH |
224-490 A/B |
- | 0.10/ 0.22 | 0.6 | 1 / 1.7 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 355 | 510/ 650 |
| - | P355N/NH |
225-490 A/B |
19Mn6 | 0.2 | 0.5 | 0.9 / 1.7 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.5 | 0.08 | 0.05 | 0.03 | 0.1 | 355 | 430/ 630 |
| A204-A | 16Mo3 | 243 | 15Mo3 | 0.12/ 0.20 | 0.35 | 0.4/ 0.90 | 0.03 | 0.03 | - | 0.3 | 0.3 | 0.3 | 0.25/ 0.35 | - | - | - | 275 | 440/ 590 |
| A387-12-2 | 13CrMo45 | 620 B | 13CrMo44 | 0.08/ 0.18 | 0.35 | 0.4/ 1.00 | 0.03 | 0.03 | - | 0.7/ 1.15 | 0.3 | - | 0.4/ 0.60 | - | - | - | 300 | 450/ 600 |
| A387-11-2 | - | 621 B | - | 0.09/ 0.17 | 0.5 | 0.400.65 | 0.03 | 0.02 | 0.02 | 1/ 1.50 | 0.3 | 0.3 | 0.45/ 0.60 | - | - | - | 340 | 515/ 690 |
| A387-22-2 | 10CrMo910 | 622-515B | 10CrMo910 | 0.08/ 0.14 | 0.5 | 0.4/ 0.80 | 0.03 | 0.03 | - | 2/ 2.50 | 0.3 | - | 0.3/ 1.10 | - | - | - | 310 | 520/ 630 |
| A387-5-2 | - | - | - | 0.15 | 0.5 | 0.3/ 0.60 | 0.04 | 0.03 | - | 4/ 6.00 | 0.3 | - | 0.45/ 0.65 | - | - | - | 310 | 515/ 690 |
| A387-9-2 | - | - | - | 0.15 | 1.0 | 0.3/ 0.60 | 0.03 | 0.03 | - | 8/ 10.0 | - | - | 0.9/ 1.10 | - | - | - | 310 | 515/ 690 |
TOBOGROUP deal with steel plate and tube already more than 10 years, every year sell
more than 80000 tons of stainless steel pipe and tube. Our client already cover more than 45 countries.
Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical,
Chemical
Industry, Food plant, Paper plant, Gas and Fluid Industry etc.
Why choose us!
1. We are the specialized supplier of stainless steel materials, can provide the best price!
2. We have more than 30 years experience in exporting products to worldwide countries, can provide the high quality products!
3. We have three thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and 7-day 24-hour services.
4. Wide excellent experiences with after-sale service.
5. Every process will be checked by responsible QC which insures every product's quality.
6. Professional packing teams which keep every packing ely.
7. Trial order can be done in very short time.
8. Samples can be provided as your requirements.
