0.3 - 350 MM Thick 5005 Aluminium Alloy Plate For Marine Aluminum Plate / Coil
5005 Aluminium Alloy Plate For Marine Aluminum Plate / Coil
| Grade: |
5000 Series
|
Temper: |
T3-T8, O,T3,T4,T351,T361,etc
|
Type: |
Plate
|
| Application: |
Aerospace industry,Auto industry,Oil and Gas industry
|
Thickness: |
0.3-350mm
|
Width: |
1000-3000mm
|
| Surface Treatment: |
Coated, brushed,polished,mill finished,power coated,sand blast.
|
Alloy Or Not: |
Is Alloy
|
Place of Origin: |
Shanghai, China (Mainland)
|
| Brand Name: |
TOBO
|
Model Number: |
5005
|
Materia: |
5005 aluminium alloy plate for marine
|
| Packing: |
LCL,FCL,nude cargo,etc.
|
Productive Technology: |
cold-drawing,hot rolling,cold rolling,forging,casting
|
Surface Protection: |
oleophobic coating,protective film,paint coating
|
| Certificate: |
SGS,CE,BV,UT,etc.
|
Original: |
the People's Republic of China
|
Payment Term: |
T/T,L/C,Western Union,etc.
|
| Shape: |
Circle,Square,etc.
|
Packaging & Delivery
| Packaging Details: | 5005 aluminium alloy plate for marine Standard Seaworthy Packing 20ftGP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ftGP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ftHC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Delivery Detail: | 3-7 days for stock size,20-35 days for custom size |
| Material | aluminum alloy plate/sheet |
| Grade | 2024,2014,3003,5052,6063,7075,etc. |
| Standard | GB/T 6893-2000,GB/T6519-2000,GB/T 3190-2008,etc. |
| Shape | round,square,rectangular,etc. |
| Thickness(mm) |
2,3,6,8,10,12,14,16,18,20,22,25,28,30,32,35,38,40,42,45,48,50, 52,55,58,6065,70,75,80,85,90,95,100,105,110,115,120,125,130, 140,150,... ...,190,200. |
| Width(mm) | 1000,1220,1250,1500,1620,1800,2000,2500,3000. |
| Length(mm) | 2000,2440,2500,3000,3240,3600,4000,5000,6000. |
| Temper | 0,F,T3,T5,T6,T651,T6510,etc. |
| Surface Treatment | brushed,polished,mill finished,power coated,sand blast. |
| ProductiveTechnology | hot rolling,cold rolling,forging,casting,etc. |
| Surface Protection | oleophobic coating,protective film,paint coating |
| Packing | LCL,FCL,nude cargo,etc. |
Temper Description
| F | As fabricated (no mechanical property limits specified). |
| O |
Annealed - products achieving the required annealed properties after hot forming processes may be designated as O temper. |
| H112 |
Slightly strain-hardened from working at an elevated temperature from a limited amount of cold work (mechanical property limits specified). |
| T3 | Solution heat-treated, cold worked and naturally aged. |
| T351 |
Solution heat-treated, stress-relieved by controlled stretching (permanent set 0.5% to 3% for sheet, 1.5% to 3% for plate, 1% to 3% for rolled or cold-finished rod and bar, 1% to 5% for hand or ring forging and rolled ring)and naturally aged. The products receive no further straightening after stretching. |
| T4 | Solution heat-treated and naturally aged. |
| T5 | Cooled from an elavated temperature shaping process and then artificially aged. |
| T6 | Solution heat-treated and then artificially aged. |
| T651 |
Solution heat-treated, stress-relieved by controlled stretching (permanent set 0.5% to 3% for sheet, 1.5% to 3% for plate, 1% to 3% for rolled or cold finished rod and bar, 1% to 5% for hand or ring forging and rolled ring) and then artificially aged. The products receive no further straightening after stretching. |
Plate is used in heavy-duty applications in the aerospace, machinery, and transportation markets.
Aluminum plate, machined to shape, forms the skins of jumbo jets and spacecraft fuel tanks. It is used for storage tanks and containers in many industries and, because many aluminum alloys actually gain strength at supercold temperatures, it is especially useful in holding cryogenic (very-low-temperature) materials.
Plate provides structural sections for rail cars and large ships, as well as armor protection for military vehicles and trucks that carry payroll.
Sheet, the most widely used form of aluminum, is found in all of the aluminum industry's major markets.
