Seamless Stainless Steel Elbow , Industrial Forged 90 Degree Elbow
Stainless Steel Seamless 90 Degree Elbow WP5 ASME B16.9 ASTM A234 WP5
Quick Details
| Material: |
Alloy, A234WP5
|
Technics: |
Forged
|
Type: |
Elbow
|
| Place of Origin: |
Shanghai, China (Mainland)
|
Model Number: |
60.3mm-610.00mm
|
Brand Name: |
TOBO
|
| Connection: |
Welding
|
Shape: |
Equal
|
Head Code: |
round
|
| Name: |
Seamless Elbow
|
Standard: |
ASME B16.9
|
Outer Diameter: |
60.30-610.00mm
|
| Wall thickness: |
6.00-59.54mm
|
Bend Angle: |
90Degree
|
Bend Radius: |
Long Radius
|
| Bevel ad ends: |
According to the model of butt-welded bevel or requirements
|
Making method: |
hot pushed
|
Packaging & Delivery
| Packaging Details: | In wooden cases or as requirement |
| Delivery Detail: | 5-25days after contract |
Specifications
Name-Seamless elbow
Standard-ASME B16.9
O.D.-60.30-610.00mm
W.T.6.00-59.54mm
Material-A234WP5
- Extensive exporting experience
- A great deal of factory resource
- 100% Quality control
- Delivery on-time
| NAME | 90D LR ELBOW |
| SIZE | 1/2"-24" |
| WALL THICKNESS | SCH10-XXS |
| CONNECTION | BUTT WELDING |
| MATERIAL | ASTM A234 WP5 |
| STANDARD | ANSI/ASME B16.9 |
| SURFACE | Black Painting |
| CERTIFICATE | ISO9001,PED. |
Specifications
180 degree elbow
Standard-ASME ANSI JIS ISO
Material-Alloy steel.
Size-1/2-28 inch
Certificate:ISO9001-2000
Product Catalogue
1, Intermediate frequency bends from D18mm to D1220mm
2, Seamless elbows from D22mm to D820mm
3, Seamless tees, reducers, and caps from D25mm to D820mm
4, Pipe fitting made of steel plate from D630mm to D3320mm
5, Socket welding pipe fittings from D3mm to D159mm
6, High-medium-low pressure flanges and blind flanges from D18mm to D2420mm
7, Barred Tees from D18mm to D1220mm
8, Factory piping assemblies from D18mm to D1420mm
A234WP5 elbow
standard-ASME ANSI DIN EN
material-P11 P12 P22 P5 P9 P91 12Cr1MoV
size-1/-30inch sch10-160,XXS
certificate-ISO
| certificate | TOBO INDUSTURY (SHANGHAI) Co.,Ltd | ||||||||
| item | A234WP5 elbow | ||||||||
| product | elbow,tee,reducer,pipe bend bend,pipe cap | ||||||||
| material | alloy steel (A234WP11 WP5 WP22 WP91 WP9 12Cr1MoV 15CrMo) carbon steel( SA106 Gr.B SA106Gr.C WPB WPC WPL6 ST35.8 ST45.8) |
||||||||
| size | 1/2-30 inch sch10-sch160,XXS | ||||||||
| standard | ANSI ASME ISO DIN EN | ||||||||
| radius of curvature |
1D-10D | ||||||||
| bend degree | 30 deg,45 deg,60 deg,90 deg,180 deg | ||||||||
| surface treatment |
rust proof oil,anticorrosion resistant.3LPE coating | ||||||||
| package | seaworthy package, plywood cases,pallet ro according to customers' requirement | ||||||||
| inspection | UT,X-ray detection | ||||||||
| certificate | ISO9001-2000,API,CE | ||||||||
| delivery term | FOB(30% deposite,the balance before shipment) CIF(30% deposite,the balance against with the copy of B/L or 30% deposite 70% L/C at sight or 100% L/C at sight) |
||||||||
| The third party inspection |
BV SGS TUV and other party allowed by clients | ||||||||
| application | petroleum,chemical,power,gas,boiler heat,exchange,shipbuilding,construction | ||||||||
