CuNi10Fe1Mn 90/10 Copper Nickel Tubes , Heat Exchanger Copper Tubes
CuNi10Fe1Mn 90/10 copper nickel tubes, heat exchanger copper tubes
90/10 Copper Nickel ( 90/10 Copper Nickel tube )
ASTM B111 C70600/ ASME SB111 C70600/BS 2871 PART 3 CN 102/EN 12451 CUNI1O FE1MN/NFA51 102 CUNI 10FE1MN/JIS H3300 C 7060
70/30 Copper Nickel
Technical Specification
BS 2871 PART III/72 CN 102 & 07 EQUIVALENT SPEC.
ASTMB C70600 & 71500
| Chemical Requirements | C70600 | C71500 |
| Copper | Remainder | Remainder |
| Iron | 1.0 to 2.0% | 0.4 to 1.0% |
| Nickel | 10 to 11% | 30 to 32% |
| Manganese | 0.5 to 1.0% | 0.5 to 1.5% |
| Total Imp. | 0.30% max. | 0.30% max. |
| Physical Properties | ||||
| Condition | T.S. Kg/mm2 | EL% Min | T.S. Kg/mm2 | EL% Min |
| Annealed (O) | 35 | 35% | 37.5-46 | 30% |
| As manufactured (M) | 44 min | - | 51 min | - |
Further Tests
- Drift Test
- Hydraulic Test
- Microstructure
- Eddy Current Optional
Uses
Gr I : Excellent corrosion resistant to turbulently used in condensers forcoastal power plants, petroleum refineries and chemical plants.
Gr II : High impingement corrosion resistant to brackish sea water atvelocities upto 3 to 4 m/sec used in desalination plants and othersea water condenser application.
