1.2mm 1.25mm CuNi 90/10 C70600 Seamless Copper Nickel Tube / Pipe
Price:
negotiable
MOQ:
1 pcs
Delivery Time:
7-15 work days
Brand:
TOBO
Product Description
1.2mm 1.25mm CuNi 90/10 C70600 Seamless Copper Nickel Tube/pipe from China supplierfor air conditioner
Copper Nickel tube C70600 ASTM B111
The seamless copper nickel pipe/tube C70600 which is widely used for Evaporator,Heat Exchanger,Condenser,Distiller.
under standard ASTM B111, we can provide alloy tube C71500, C70600, C71640, etc.
Copper Nickel tubes, 10% – C70600 - exhibits excellent resistance to impingement attack. It is also highly resistant to SCC. This alloy is suitable for Marine condenser tube installations in place of Aluminum Brass, especially where higher water velocities are encountered.
UNS No. |
C70600 – BSI No. CN102 – ISO Name CuNi10Fe1Mn |
Chemical Comp. (%) |
Cu rem / Ni 9 ~ 11 / Pb 0.05 / Fe 1 ~ 1.8 / Zn 1 max / Mg 1 max |
ASTM Spec. |
B 111, B 395, B 466, B 552 |
ASME Spec. |
SB 111, SB 395, SB 466 |
Applications |
Condenser, Evaporator and Heat Exchanger tubes; Distiller tubing; Salt Water piping. |
Temper |
O61 Annealed / H55 Light-Drawn |
Properties * |
|
Density |
0.323 lb/in³ |
Tensile Strength min.- O61 -/- H55 |
40 ksi -/- 45 ksi |
Yield Strength min.- O61 -/- H55 |
15 ksi -/- 35 ksi |
CTE, linear |
9.5 10-6/°F @ 70.0 – 570 °F |
Specific Heat Capacity |
0.09 BTU/lb-°F @ 70ºF |
Thermal Conductivity |
26 BTU/ft2/ft/h/°F @ 70.0 °F |
Melting Point |
2010 – 2100 °F |
Spec Equivalents: ASTM B151, MIL C15726F
The C71500 COPPER NICKEL "70/30" alloy is the corrosion resistant alloy mainly used in salt water environment. The alloy is the combination of nickle, iron and manganese that helps in maintaining good corrosion resistance and is commonly used in valves, and pump components.
Applications:
-
Industrial Applications : Pump Impellers, Heat Exchanger Tubes, Evaporator Tubes, Distiller Tubes, Condenser Plates, Refrigerators, Process Equipment, Condenser Components, Ferrules, Welding Backing Rings, Flexible Metal Hose, Weld Wire, Boiler Parts, Condensers, Propeller Sleeves, Heat Exchanger Components
-
Marine Applications : Salt Water Flanges, Salt Water Piping, Valve Bodies, Sea Water Service, Fittings, Sea Water Condensers, Salt Water Pipe Fittings, Water Boxes - Salt Water Applications, Pump Bodies and Internal Parts-Sea Water
Specifications
End Product |
Specification |
Bar |
ASTM B122, B151, MILITARY MIL-C-15726, SAE J461, J463 |
Bolts |
ASTM F468 |
Electrode, Welding |
AWS A5.6, MILITARY MIL-E-22200/4 |
Nuts |
ASTM F467 |
Pipe, Seamless |
ASME SB466, ASTM B466 |
Pipe, Welded |
ASTM B608, B467 |
Plate |
ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Plate, Clad |
ASTM B432 |
Plate, Condenser Tube |
ASME SB171, ASTM B171, SAE J463, J461 |
Rod |
ASTM B151, MILITARY MIL-C-15726 |
Screws |
ASTM F468 |
Sheet |
ASTM B122, MILITARY MIL-C-15726, SAE J463, J461 |
Strip |
ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Studs |
ASTM F468 |
Tube, Condenser |
ASME SB111, ASTM B552, B111, MILITARY MIL-T-15005, SAE J463, J461 |
Tube, Finned |
ASME SB359, ASTM B359, MILITARY MIL-T-22214 |
Tube, Seamless |
ASME SB466, ASTM B466, MILITARY MIL-T-16420 |
Tube, U-Bend |
ASME SB395, ASTM B395 |
Tube, Welded |
ASME SB543, ASTM B543 |
Wire |
MILITARY MIL-C-15726 |
Physical Properties:
Product Property |
US Customary |
Metric |
Coefficient of Thermal Expansion |
9.0 ·10-6 per oF (68-572 F) |
16.2 ·10-6 per oC (20-300 C) |
Density |
0.323 lb/in3 at 68 F |
8.94 gm/cm3 @ 20 C |
Electrical Conductivity |
4 %IACS @ 68 F |
0.027 MegaSiemens/cm @ 20 C |
Electrical Resistivity |
225.0 ohms-cmil/ft @ 68 F |
37.4 microhm-cm @ 20 C |
Melting Point - Liquidus |
2260 F |
1238 C |
Melting Point - Solidus |
2140 F |
1171 C |
Modulas of Elasticity in Tension |
22000 ksi |
152000 MPa |
Modulus of Rigidity |
8300 ksi |
57230 MPa |
Specific Gravity |
8.94 |
8.94 |
Specific Heat Capacity |
0.09 Btu/lb/oF at 68 F |
377.1 J/kg · oK at 293 K |
Thermal Conductivity |
17.0 Btu · ft/(hr · ft2·oF)at 68F |
29.4 W/m · oK at 20 C |
