6" SCH40 ASTM A403 / ASTM A234 / ASTM A420 / ASTM A815 / ELBOW 45° LONG RADIUS.

Price Negotiable

Price: 1.2USD

MOQ: 1 PCS

Delivery Time: 7work days

Brand: TOBO

Product Description

6" SCH40 ASTM A403 / ASTM A234 / ASTM A420 / ASTM A815 / ELBOW 45° LONG RADIUS.

We are a SA403 S31254 elbow,254SMO Elbow,stainless steel elbow,Tee,ASME B16.9 Butt weld Pipe Fitting manufacturer,We can offer both Seamless and Welded type butt weld fittings.

We can produce high quality stainless steel elbow
180deg stainless steel ASTM A403 WPS31254 elbow
90deg stainless steel ASTM A403 WPS31254 elbow
45deg stainless steel ASTM A403 WPS31254 elbow

Products		Size
ASTM A403 WPS31254 SS Elbow – Long Radius	ASTM A403 WPS31254 SS Stub Ends	Sizes 1/2″ – 48″
ASTM A403 WPS31254 SS Elbow – Short Radius	ASTM A403 WPS31254 SS Cross
ASTM A403 WPS31254 SS Reducing Elbow	ASTM A403 WPS31254 SS Reducing Cross
ASTM A403 WPS31254 SS 45° Elbow	ASTM A403 WPS31254 SS Tees
ASTM A403 WPS31254 SS Fabricated Tee	ASTM A403 WPS31254 SS End Cap
ASTM A403 WPS31254 SS Reducer	ASTM A403 WPS31254 SS Coupling
ASTM A403 WPS31254 SS Concentric Reducer	ASTM A403 WPS31254 SS Pipe Nipple
ASTM A403 WPS31254 SS Eccentric Reducer	ASTM A403 WPS31254 SS 5D Elbow
ASTM A403 WPS31254 SS 3D Elbow	ASTM A403 WPS31254 SS Welded Pipe Fittings

ASME SA403 WPS31254 Stainless Steel Buttweld Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS WP321	1.4301	S30400	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10

Stainless Steel S31254 1.4547 Pipe Fittings Chemical Composition

SMO 254	Ni	C	Mo	Mn	Si	Fe	Cu	S	P	Cr
SMO 254	17.5 – 18.5	0.02 max	6 – 6.5	1 max	0.8 max	–	0.5 – 1	0.01 max	0.03 max	19.5 – 20.5

SMO 254 Duplex Buttweld Pipe Fittings Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.0 g/cm3	1320-1390 ℃	300	650	35 %

Equivalent Grades for 1.4547 Stainless Steel Fittings

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	SIS	GOST
SMO 254	S31254	1.4547	Z1 CNDU 20.18.06Az	X1CrNiMoCuN20-18-7	–	2378

Elbow 90° Long Radius Dimension

LONG RADIUS ELBOWS (R = 1,5 ND) ANSI B 16.9 dimensions
inches	ND	mm	Center to center	Radius	Center to end	Back to face
D			O	A	B	K
1/2	15	21,34	76,20	38,10	15,87	47,62
3/4	20	26,67	57,15	28,57	11,11	42,86
1	25	33,40	76,20	38,10	22,22	55,56
1 1/4	32	42,16	95,25	47,60	25,40	69,85
1 1/2	40	48,26	114,30	57,15	28,57	82,55
2	50	60,32	152,40	76,20	34,92	106,40
2 1/2	65	73,02	190,50	95,25	44,45	131,80
3	80	88,90	228,60	114,30	50,80	158,75
3 1/2	90	101,60	266,70	133,35	57,15	184,15
4	100	114,30	304,80	152,40	63,50	209,55
5	125	141,30	381,00	190,50	79,38	261,90
6	150	168,27	457,20	228,60	95,25	312,70
8	200	219,07	609,60	304,80	127,00	414,30
10	250	273,05	762,00	381,00	158,75	517,50
12	300	323,85	914,40	457,20	190,50	619,10
14	350	355,60	1066,80	533,40	222,25	711,20
16	400	406,40	1219,20	609,60	254,00	812,80
18	450	457,20	1371,60	685,80	285,74	914,40
20	500	508,00	1524,00	762,00	317,50	1016,00
22	550	558,80	1676,40	838,20	342,90	1117,60
24	600	609,60	1828,80	914,40	381,00	1219,20
28	700	711,20	2133,60	1066,80	441,90	1422,40
Dimensions in mm.
