Flexible Outer Fiber Braided Rubber Hose 300 PSI For Petroleum Water Air
Flexible Outer Fiber Braided Rubber Hose 300 PSI for Petroleum Water Air
Outer Braided Rubber Hose
Structure: Tube: Pure rubber tube. It can be designed as to be heat, oil, acid, alkaline and wear resistant hoses according to the requirements of application.
Reinforcement: High tensile polyester fiber braided.
Outer cover: Stainless steel wire, or Aluminium wire, or cotton threads, or polyester fiber lines, which is used for strengthening pressure or protection.
Temperature: -40ºC - +150ºC, customized according to application.
Tube color: Black, etc.
Application: Mainly used for conveying of air, insert gas and water in mining, construction, engineering, shipbuilding, steel production etc.
Standard length: 50m, 100m.
Specification of the inner hose:
| Item code | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Length | Measurement | Weight | |||
| inch | mm | mm | bar | psi | bar | psi | m | cbm/roll | kg/m | |
| PRA-06 | 1/4" | 6 | 13 | 20 | 300 | 60 | 900 | 100 | 0.0256 | 0.17 |
| PRA-08 | 5/16" | 8 | 15 | 20 | 300 | 60 | 900 | 100 | 0.0271 | 0.22 |
| PRA-10 | 3/8" | 10 | 17 | 20 | 60 | 60 | 900 | 100 | 0.036 | 0.26 |
| PRA-13 | 1/2" | 13 | 22 | 20 | 300 | 60 | 900 | 100 | 0.0634 | 0.4 |
| PRA-16 | 5/8" | 16 | 25 | 20 | 300 | 60 | 900 | 50 | 0.1095 | 0.45 |
| PRA-19 | 3/4" | 19 | 29 | 20 | 300 | 60 | 900 | 50 | 0.146 | 0.7 |
| PRA-25 | 1" | 25 | 36 | 20 | 300 | 60 | 900 | 50 | 0.171 | 0.85 |
Note: The inner hose can also be Pure rubber tube without fiber braided reinforcement.
If the specifications you need are not in the list, please offer your specification parameters or operating requirements. We'll check and customize.
