Morden Style Soundproofing Folding Partition Walls for Conference Room
High Quality Exhibition Aluminum Operable Partition Walls with Sliding Doors
Specification:
BUNGE movable partition walls is made of high quality anodized aluminum frame with environmentally composite materials.the panels move on a ceiling track with no requirement of floor guides or rails.,the panel has a standard thickness of 65mm ,80mm and 100mm,and a width up to 1219mm.Maximum height can reach 17meter tall.
The movable partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant,schools,office,religion,hospitals,shopping arcades and many other indoor applications product.
Features:
1. Large selection of standard finishes
2. Retractable top and bottom seals retract for easy movement
3. Deep interlocking vertical seals prevent sound leaks and help to align the panels during set-up
4. No floor track
5. Quick sight and sound division with a simple pull-and-latch operation
Bunge Operable Wall Systems-Technical Information
| Item | Movable Partition Wall | |||
| Material | Melamine, Glass, Fabric,MDF | |||
| Type | Tempered Glass Partition Wall | |||
| Acoustic Folding Partition | ||||
| Surface Finish | 1. MDF Base board with Melamine Finish | |||
| 2. MDF board with Fabric Or Leather Finish | ||||
| 3. Plywood Or MDF base board without any finish | ||||
| Size and Design | Customized | |||
| Opening Style | Folding | |||
| Structure | Aluminum track, Trolley bearing, Acoustic Door Panel | |||
| Series | Thickness (mm) | Applied height (m) |
Sound Insulation(db) |
Referenced Weight |
| 65 | 65 | 2.0~4.5 | 32-36 | 30kg/m2 |
| 80 | 80 | 3.0~6.8 | 35-45 | 35kg/m2 |
| 100 | 100 | 5.0~8.0 | 43-53 | 45kg/m2 |
| 125 | 125 | 7.2~13.3 | 53-60 | 65kg/m2 |
| Package | 1. Inner: Vacuum soft plastic film | |||
| 2. Outer: Carton / strong chipboard | ||||
| Installation | Easy Installation, Provide the installation instruction | |||
| Application | Meeting room, dining hall, exhibition hall, Function room,office etc. | |||
| Delivery Time | 35-45 days after receiving the deposit and confirming the shop drawing | |||
| Advantages | 1.Good performance of sound insulation, thermal insulation and Fire prevention | |||
| 2.Save much space for your building | ||||
| 3. No tracks on the floor, it’s easy to install and remove | ||||
| 4.Beautiful appearance, it is widely used in many spaces, such as meeting room,dining hall, exhibition hall, Function room and office | ||||
| 5. We can add single or double doors on the board for convenience | ||||
| 6. Supplied our products for many projects all over the world | ||||
Suitable used in:
Soundproof movable partitions can be used to Convention Centers, Gymnasiums, Religious Facilities, Hotel, Auditoriums, Corporate Training Facilities, Civic or Exposition Halls, Schools, Banquet Facilities etc. Soundproof movable partition systems, there are no more barriers to maximizing the potential of your available building spaces.
