Fiberglass Ceiling Board Sound And Fire Insulated Decorative Wall Panels

Features:

1.Perforated wooden acoustic panel is manufactured from 100% polyester fibers and does not contain chemical binders including formaldehyde.

2.Perforated wooden acoustic panel products contains a minimum of 75% previously recycled polyester fiber (from PET bottle flake)ensuring comparatively low embodied energy.

3.Its polyester non-woven surface is easy to be bonded and fit for most kinds of surface sheet.

4.Absorb reverberated sound, providing acoustic control to lessen the amount of noise in a room

5.Protect and adorn your walls, providing high-impact wall protection while serving as a viscous surface, giving the same functionality as a bulletin board without sacrificing aesthetics

6.Easy-to-install, cuts, fastens, and paints easily, less maintenance, more life;

7.It is widely used for acoustic walls, acoustic ceilings, computer rooms, TV station, gymnasium, theater,office, cinema, church, hospital etc.

Product Specifications

Product Name:Polyester fiber acoustic panel
Composition:100% Polyester Fiber (PET)
Panel Dimensions :2420*1220mm or other Custom size
Thickness :(+/– 10%) 9mm and 12mm color in stock or 3mm.6mm.15mm,24mm.48mm
Weight: (+/– 5%) 1400g/sqm(155kg/m3).1650g/sqm(183kg/m3).2000g/sqm(222kg/m3) for 9mm in stock.
2400g/sqm(200kg/m3) for 12mm in stock.
2800g/sqm(117kg/m3) for 24mm
Density:1lb/cubic foot=16kg/m3.

Installation-procedures

1.Messuring the size of the wall.Marking sure the installation position,horizontal line and vertical line.Setting aside enough space for eelectric wire socket,tubs and so on.

2According-to-the-actual-size-of-the-place,-caculate-and-cut-some-panels-and-keels.Thenleave-aside-space-for-socket,-tube-and-other-thing.

3The-installation-order-must-obey-the-principle-from-left-to-right,-from-below-to-above-when-installed-horizontally-the-panel-leaves-its-female-side-above.-When-installed-vertically,-its-female-side-is-on-the-right.

4Fix-the-panel-on-the-keel.

5.Use-the-screw-to-fix-on-the-side.-When-installing-the-right-o upper-keel,-leave-1.5mm-horizontally-for-expansion-and-then-use-the-silica-to-seal-it-up

Applications:

It is suitable for office, meeting room, auditorium, KTV, exhibition room, stadium, hotel ect.

Polyester acoustic panel is an ideal decorative and acoustic material, made of

100% polyester fiber with density of 229kg/M3. It's has good performance: eco-friendly, fire-

resistance, heat insulation, moisture-proof and mildew. Many patterns and colours are available to meet different levels of acoustic styles and decorative requirements.
