Mdf Acoustic Board Wooden Timber Perforated Sound Absorbing Panels
Product Specifications
Name : Perforated acoustic panel
Features:
1 Mdf soundproof acoustic board is a kind of resonance absorption material with holes through on the quality MDF board.
2 It has strong selection on the sound spectrum and particular great performance on the middle and low frequency.
3 If filled with the acoustic cotton at the back side space of the acoustic panel, it has better performance on the middle and high frequency.
4 The holes diameter and pitch can be custom made.
5 Strong impact resistance, excellent decorate performance, elegant color, especially work for wooden construction.
Model type | T-3/9-16 | T-2/9-8, T-3/9- 16, T-3/9-32, T-4/10-32 |
Size(mm) | 2440*197 | 2440*133, 2440*197 |
Thickness(mm) | 18 | 12, 15, 18 |
Surface | melamine | melamine , veneer, metal finish, PU leather |
Veneer species | - | Maple, cherry, Oak, teak, walnut, ash tree, sabelli, birch |
Paint | - | UV / PU painting |
Core material | Standard MDF | Standard MDF / Fireproof MDF / Moisture proof MDF / Eco-friendly Wheat Straw MDF / Magnesium Composited MDF |
Backside material | Normal acoustic felt | normal acoustic felt / high quality acoustic felt / fiberglass felt |
Fireproof grade | GB8624 2012B1 | GB8624 2012 A / B1 |
Eco-protection grade | E1 | E0 / E1 |
Installation | aluminum keel and clips / wood frame / gun nail | aluminum keel and clips / wood frame / gun nail |
Certification* | BV,CE,SGS,ISO9001-2008 | BV,CE,SGS,ISO9001-2008 |
Test report* | Eco protection, sound absorption, flame retardant | Eco protection, sound absorption, flame retardant |
Applications:
Theater, cinema, recording studio, office, television broadcasting station, gymnasium,
conference hall, multifunction hall, recording studios, cinema, boardrooms,
theatres, churches, court rooms, hotel foyers, reception areas, schools, KTV and villa
