Construction & Real Estate Soundproofing Materials Acoustic Panels
China Sound Insulation Material Wooden Grooved Acoustic Panel Wood Wall Paneling for sale

Sound Insulation Material Wooden Grooved Acoustic Panel Wood Wall Paneling

Price Negotiable
Price: 12 - 38 dollars per square meters
MOQ: 100 square meters
Delivery Time: 15-20 days
Brand: BANGE
Product Description

Grooved Wood Acoustic Covering Wall Panels

Features:

1. Finishes: Melamine, Wooden veneer, fireproof surface, painting.


2. Acoustic tissue: Black felt attached on the back for fireproof and soundproof.

3. Type: 13/3, 14/2, 28/4, 59/5 or made on your kindly request.

4. Specification: L2440mm*W128mm*H15mm, L2440mm*W128mm*H18mm, or made on your kindly request.

5. Thickness: 12/15/18mm

6. Tolerance: Width is 0.1mm, length is 2mm.

7. Color: Choose as to our color samples or made on your kindly request.

BUNGE Acoustic wood panels are available in three main finishes, Wood Veneer, High quality paint finish, and decorative Laminate. This gives the designer almost an unlimited choice in designing the wall or ceiling finish. TheTengfei Acoustic wood panels range includes standard wood veneers chosen from the most popular colours available, as is the same with the High quality decorative laminates.



REAL WOOD VENEER

The standard range of wood veneers is available on an exstock basis, however Tengfei can choose from international suppliers quality veneers to match your choice



Paint Finish

BUNGE Acoustic wood panels are available in either Pantone or RAL colours. This gives almost an unlimited choice in selection. The paint finish is in a high quality 2pac finish and can be supplied in Gloss, Matt or Satin finishes.



Decorative Laminate

BUNGE Acoustic Wood Panels come in a standard range of Decorative laminates

MDF grooved Acoustic wall Panel

Wooden Grooved Acoustic Panel
1.Structure Basic Material ,Finish&Back Finish
2.Basic Material E1 MDF,FR MDF ,MgO Combination Board etc.
2. Front Finish Melamine ,Natural Wood Veneer,Paint,etc.
3. Back Finish Black Acoustic Felt
4.Standard Size 2440*133 , 2440*197mm,etc.
5.StandardThickness 12/15/18mm
6. Standard Pattern 13-3,14-2,28-4,59-5,etc.
7. Installation 1.Lightweight steel keel system2.Wooden battern systern
8. Fire rate can meet China Standard Class B1 and BS476 Part 7 Class 1
9. Eco level can meet China and EU Standard Class E1
10.Applications gymnasium,hotels,exhibition centers,schools,studio etc.
11.Is customized can be Customized


Installation Methods
A)Preparation
1.The place of installation must be dry,with the lowest temperature no less than 10 degrees celsius.
2.the acoustic panels to be installed must be placed in the place of installation for at least 48h in order to adapt the indoor environment.
3.After installation ,the largest humidity changing rate of the place of installation should be between 40%-60%.
4.The distance between each wood keel must be less than 500mm and that between each light steel keel should no more than 600mm.
B)Installation
1.Confirm the place of installation ,determine the horizontal and vertical lines and the reserved measurements for the electric wire socket ,pipes.etc.
2.Calculate the actual construction measurements and cut the part of acoustic panels if needed.
3.Start to install and follow the rules:from left to right,from bottom too top.for horizontally installation.make the grooves up;for the vertical installation,make the tougues on the right.for real wood veneer acoustic panels that have requirements on the direction of the stripes,the panels should be installed according to the pre-marked sequence numbers.
C)Installation system
1.Lightweight steel keel system
2.Wooden batten system

Application places:

Suitable for opera, theater, recording studio, recording studio, studio, audition room, business office, television, radio, multi-purpose hall, meeting rooms, studio, concert hall, auditorium, gymnasium, large Casino, hotel, KTV, luxury villa or home life more stringent requirements of the acoustic spaces.
