Banquet Hall Acoustic Movable Wooden Room Partition / Sliding Sound Proof Partition Wall

Banquet Hall Acoustic Movable Wooden Room Partitions Soundproof Sliding Partition Walls


The details of sliding partition walls

Model: BG65,BG85,BG100 Sliding Partition Wall

Sliding Partition wall thickness: 65mm~2.56inch, 85mm~3.35inch, 100mm~3.9inch

Board thickness: 9mm or 12mm

Blinds thickness: 16mm,25mm

Sliding Partition-wall standard length: ANY

Sliding Partition-wall standard height: 2000—13000mm, 78.7inch ~ 512inch

Optional material: Fabric/Melamine board/Glass/metal board/Aluminum Composite Panel/Soft panel/Blinds/Wooden board

Description sliding partition wall / folding door / movable wall /

Characteristic: Movable / Stable Structure/ Sound insulation / Pro-environment/ fireproofing / Stylish
Product dominant: Design systematization / Industrialization productions / Standardization Installation / Diversification working / Modernization appearance

Service: Supply consulting service, CAD project, office layout design /Work environment consulting /Products instruction

Sales Countries: Mace in china. Sales all over the world.


Specifications of Acoustic Sliding Partition Walls System

The 65 mm frame of the sliding partition walls

The frame of the 65-type sliding partition walls refers to the material used for the frame when the door panel is spliced. The 6055-T6 high-hardness aluminum alloy material can be used as the raw material for the partitioning aluminum alloy. The conventional oxidation color can be processed according to the customer's other colors.

The total thickness of the 65-type sliding partition walls frame can be 65mm. According to the thickness of the door panel, there are several models such as 65 type, 85 type and 100 type.

The 6-type mobile sliding partition walls uses 9mm slots on both sides as the fixed position of the board, and the middle is filled with soundproof cotton. Built-in transmission rod, with the principle of jack, easy to lock the sliding partition wall with the transmission setting, the fixed partition wall is as strong and solid as the solid wall. As long as the track is pre-buried before the ceiling is made, there is no need to lay the track on the ground.
