Interior Soundproof Wall Dividers Sliding Door Roller Conference Hall Movable Wall Partition System

Description:

Acoustics movable wall offers unique custom made Acoustic Movable Wall Partitions which facilitates in managing.

Your space to its maximum capacity. Our Acoustic Movable wall partition system constitutes of panels.
Suspended individually from the rail fixed to the top of the roof. The Acoustic Movable wall partition has retractable top and bottom seals which interlocks each panel to its position.

If required, hinged pass doors shall be provided through the Acoustic Movable Wall Partition where access is required.

Technical information:

Feature:

1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;

2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;

3. Soundproof and environmental protection: sound insulation effect is good;

4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;

5.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance;

6. Wide range of applications: Can be used in conference halls, exhibition halls, restaurants, high-cleaning factories and offices.

Feature:

Top hung with no floor track.

Scissor-jack operating mechanism.

Available with virtually any surface finish.

Ideal for conference centres, hotels, offices & schools.

Angled, glazed, corner or junction panels for maximum flexibility.

Single or double point suspension for versatile stacking options.

Panels with hinged pass door, single or double leaf inset pass door panels for access through.

Movable partition wall structure:

When the movable partition is closed there are no visible aluminium profiles and the continuity of the covering panels surface is granted by the perfect alignment of the elements.

The vertical profiles, studied for for the edging of the elements, are coupled with male/female system and the finishing panels are completely enclosed within the aluminium frame. Each element has two sliding rubber blocks, linked to mobile seals with soft gaskets: through a pressure on them, the locking mechanism start to work and allows the locking in positions of the elements.

The last element of the partition has one more moving telescopic mechanism, with a side sliding. This mechanism is manually operated by a control placed on a side of the element itself.

Our service:

1. Profession--We have professional sales staff. Any questions will be replied within 24 hours.

2. Price--Because we are factory , so we can provide higher quality and lower price products.

3 . Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.

4. Team--We have our own engineering department, according to your request for your tailor-made for your product.
