Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls
Soundproof Operable Wall in Banquet Hall Wooden Sound Insulation Movable Partition Walls
Movable partition walls melamine finish
The movable partition walls series is the most popular specification range of fully operational single-panel sliding partition systems. The noise reduction of up to 50dB noise is achieved with a combination of operable top and bottom seals, high performance multiple sound absorbing material in partition walls and panel assembly design which allows noise reduction between the frame and the outer layer.
The vertical channel of each movable partition walls panel contains a polymer insert that is acoustic sealed when the panels are placed as a wall. The sound insulation partition walls are available in three thicknesses, 65mm, 80mm and 100mm, depending on the acoustic rating (from 30dB to 50dB).
Application
Movable partition wall is usually used where indoor space needs to be fully utilized. Hotels, convention centers, educational institutions, offices, training areas, etc. can all benefit from the flexibility of partition wall sound insulation system.
Movable partition walls technical details
| Height (maximum height) | 2000 - 4000 mm |
| Width | 650 - 1200 mm |
| Thickness | 65 mm |
| Left and right telescoping | 140 mm |
| Stretching up and down | 22.5 mm |
| Push and pull force | 30 N |
| Orbital load | 380 kg/m |
| Sound insulation coefficient | 45 DB |
| Panel material | MDF |
Movable partition walls operation
When the operable seal is retracted, the movable partition walls panel slide easily along a unique aluminum overhead rail system (no floor rails are required). The telescopic end panel allows the walls to be locked off to complete the acoustic seal. The rail and carrier systems make sure movable partition wall is easy to operate and change direction, allowing panel stacking in countless configurations.
For aesthetic appeal, it is possible to provide almost any decorative finish, including veneer, laminates, walls, carpets, whiteboards and decorative lacquers.
Movable partition walls features
Many panel stack options are completely flexible.
No floor track to get in the way.
Individual movable partition wall panel can be stored to maximize the use of space.
Operable top and bottom seals for easy operation.
A wide range of surface finishes are available for movable partition walls.
High performance multiple fill for maximum noise reduction.
Sound insulation aluminum frame structure, enhance the acoustic effect.
Unique track systems ensure quiet and easy operation.
Three panel thickness are available for a variety of acoustic requirements.
