Aluminum Folding Moveable Door Acoustic Partition Walls For Conference Hall

Price Negotiable
Price: $82-88 per square meter
MOQ: NO MOQ, small quantity welcome
Delivery Time: 7-15 days
Brand: EBUNGE
Product Description

Aluminum Folding Moveable Door Acoustic Partition Walls for Conference Hall

Moveable acoustic partitions advantages

1. Large selection of standard finish treatment.


2. It can quickly and easily separate the space.


3. Retractable top and bottom seals allow easy movement.


4. Quick divide by simple pull / latch operation.


5. No floor track is needed for movable partition walls for rooms.


6. Tight vertical seal prevents sound leakage and helps align the panel during installation.


7. Moveable acoustic partitions are a modern decorative style with noise insulation, heat insulation, and fireproofing function.



Moveable acoustic partitions details



Moveable acoustic partitions place all options at your fingertips, no matter it’s for room to work or room to play, public meetings or private functions, assembly or seminars, etc. Our folding partition wall dividers can easily slid along a hidden track above the ceiling, providing all the acoustics and aesthetic features of the fixed wall with an immeasurable advantage of maximum flexibility.



You can easily and quickly achieve a variety of configurations and divisions. Once in place, the spring-loaded seal locks like it’s fixed. The fully modular system allows operable partitions to be designed by project, taking into account all individual needs. The installation can be carried out local installers with our instruction. In essence, our operable panel partitions can eliminate barriers of your architectural design and take full advantage of your available space.



Our single-panel moveable acoustic partitions are designed to accommodate most specifications. Each panel is interlocking with the next. They are available in three different thicknesses: 65, 85, 100mm. Folding partition wall dividers of each thickness is different.



Moveable acoustic partition is a customizable range of partition panels that conforms to the customer’s precise specifications. As a soundproof operable system, moveable acoustic partition is the best choice for places where noise reduction and space dividing are the primary task.



For straight-line openings that do not require multiple locations or offset storage, Moveable acoustic partitions system is ideal. Fast and easy setup is possible because the panels are collected in groups and easy to move in a straight line.



Technical Information

Series

Thickness

(mm)

Applied height

(m)

Width of Intermediate

panel (m)

Acoustical reduction

coefficient (db)

Hanging weight
#65 65 2.0~4.5 0.6~1.2 35 30kg/m2
#85 85 3.0~6.8 0.6~1.2 45 35kg/m2
#100 100 5.0~8.0 0.6~1.2 53 45kg/m2
#125 120 7.0~13.0 0.6~1.2 65 65kg/m2
Model BG65 Series BG80 Series BG100 Series BG High-Series
Suspensionsystem Aluminum hanging Steal Hanging
Basic Thickness 65 mm 80 mm 100 mm 100 mm
Total thickness 65/75/85/95mm 80/90/100/110mm 100/120/130mm 100/120/130mm
Max Height Up to 3800 mm Up to 6000 mm Up to 8000 mm Up to 15000 mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/Ceiling Sealing Strength Telescopic aluminum tube with rubber strip.
Side walls sealing strength Double seal tape
Sound insulation level 26-30 db 28-34 db 32-40 db 42-52 db
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized
