Australia Conference Center Folding Acoustic Room Dividers Operable Movable Wall Partition
Australia Conference Center Folding Acoustic Room Dividers Operable Movable Wall Partition
Folding acoustic room dividers details
Our foldinga coustic room dividers system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.
When the operable seals are retracted, the folding acoustic room dividers panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the folding acoustic room dividers to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
Technical Information
| Series |
Thickness (mm) |
Applied height (m) |
Width of Intermediate panel (m) |
Acoustical reduction coefficient (db) |
Hanging weight |
| #65 | 65 | 2.0~4.5 | 0.6~1.2 | 35 | 30kg/m2 |
| #85 | 85 | 3.0~6.8 | 0.6~1.2 | 45 | 35kg/m2 |
| #100 | 100 | 5.0~8.0 | 0.6~1.2 | 53 | 45kg/m2 |
| #125 | 120 | 7.0~13.0 | 0.6~1.2 | 65 | 65kg/m2 |
| Model | BG65 Series | BG80 Series | BG100 Series | BG High-Series | |
| Suspensionsystem | Aluminum hanging | Steal Hanging | |||
| Basic Thickness | 65 mm | 80 mm | 100 mm | 100 mm | |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm | |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm | |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm | |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. | ||||
| Side walls sealing strength | Double seal tape | ||||
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db | |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | |||
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | ||||
Folding acoustic room dividers FAQ
| Q1. What is your terms of payment? | |||
| A: T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the folding acoustic room dividers and packages before you pay the balance. | |||
| Q2. How about your delivery time? | |||
| A: Generally, it will take around 30 days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
|
|||
| Q3. Can you produce according to the samples? | |||
| A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures. | |||
| Q4. What is your sample policy? | |||
| A: We can supply the free sample to all of our clients, but the customers have to pay the courier cost. | |||
| Q5. Do you test all your goods before delivery? | |||
| A: Yes, we have 100% test before delivery | |||
| Q6 : What is your main product? | |||
| A1 : We can supply the folding acoustic room dividers system(including tracks and other accessories)as well as the installation, the office furniture and some other acoustic panels. | |||
| Q7 : What is the standard size ? | |||
| A3 : Our product is CUSTOMER MADE. We always manufacture room dividers according to buyer's dimensions. | |||
| Q8: How do you make our business long-term and good relationship? | |||
| A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from. |
