Acoustic Hanging Soundproof Sliding Partition Walls For Conference Room
Acoustic Hanging Soundproof Sliding Partition Wall Dividers for Conference Room
Sliding wall dividers description
Interior decorative partition Information: BUNGE sliding wall dividers board thickness is 65 mm, it can be double or single piece, and can be designed U shape or L shape door. Every sliding wall dividers rollers can load 225kgs weight. The top and bottom flex range is 22.5mm.
Interior decorative partition Character:
A> Galvanized sheet base board: Sound insulation coefficient RW=50dB, the density is 30kg/m2;
B> MDF or plywood base board: Sound insulation coefficient RW=38dB, the density is 24kg/m2;
C> Magnesium board base board: Sound insulation coefficient RW=32dB, the density is 25kg/m2;
Interior decorative partition Usage: It is widely used at 2m~3.5m height.
Technical Information
| Model | 65 sliding wall dividers |
85 sliding wall dividers |
100 sliding wall dividers |
Ultra-high system sliding wall dividers |
| Panel Thickness | 65 MM | 85 MM | 100mm | 100mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm | 680mm-1230mm | 680mm-1230mm |
| Panel Height | 2000mm-4500mm | 3000mm-6500mm | 5000mm-8500mm | 7000mm-17000mm |
| Frame | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
32db | 45db | 60db | 60db |
|
Hermetic flex distance(mm) |
45mm | 45mm | 45mm | 60mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 | 40,45,48,55 | 60,60,60,60 |
| Faceplate Material |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass |
Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
| Panel Surface Finish |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment |
Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Common Applications:
1. studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.
2. theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.
3. meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.
4. air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.
Sliding wall dividers features
Available in top-supported or floor-supported configurations, the center-hung, paired panels are perfect for straight-line openings and offer quick, easy setup.
Hinged together in groups of two, facilitating quick, easy setup.
No auxiliary storage track or support required.
Economical overhead support of straight-line track.
Smooth operation.
All of the measurement,surface and the colors and be customized.
Simple automatic bottom seals for efficient operation.
Suited for applications that require exceptional durability, acoustic control, and frequent use.
Panels are designed to be stored at either or both ends of an opening.
Frequently used to divide classrooms, meeting rooms, or office spaces.
