Fabric Acoustic Movable Wall Davao Foldable Sliding Partition Walls For Meeting Room

Price Negotiable
Price: US $78-95 per square meter
MOQ: No MOQ, small quantity welcomed
Delivery Time: 12-20 days
Brand: EBUNGE
Product Description

Fabric Acoustic Movable Wall Davao Foldable Sliding Partition Walls for Meeting Room



Sliding partition details



Davao sliding partition wals is centralization of studying, designing, sales, manufacture, installation and after sale service. Making full use of our rich acoustic technology advantages.



Sliding partition walls (movable walls system board, and movable partition screen ) has excellent sound insulation and anti-fire features. We adopt advanced domestic and foreign technology, combined with our rich practice experience and creative design, our products have flexible movement and easily to be used.



Our sliding partition wall is widely used at exhibition hall, international conference center, hotel banquet hall, KTV, high class restaurant, government office building, school and hospital meeting room etc, and any places where need to be separated and full used easily!



This sliding partition wall has achieved all of our clients, builders and designers highly praised. We are looking forward to cooperating with more domestic and oversea clients and designers to obtain higher and common success!



Technical Information
TYPE 65A 85A 100A&125A
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 85mm 100mm
Panel height Up to 4000mm,Heights greater than 3000mm refer to our Technical Dept Up to 6000mm,Heights greater than 6000mm refer to our Technical Dept.inset Pass doors above 2400mm.Full Height pass door up to 3000mm high Document 'M'disabled doors-optional
Max height 4000mm with heavy duty track 6000mm with heavy duty track 18000mm with heavy duty track or steel track
Panel width 600-1200mm 600-1200mm 600-1200mm
Frame construction Aluminium/steel Aluminium/steel Aluminium/steel
Face material 12mm 12/15/18mm 12/15/18mm
Fire safety optional Class I or O optional Class I or O optional Class I or O
Vertical profiles Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional
Retractable seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals
Operation of seals Manual,with supplied operating handle Manual,with supplied operating handle Manual,with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass Doors Single open in oanel or double open in two panel Single open in oanel or double open in two panel Single open in oanel or double open in two panel
Sound insulation 40,44,47,50dB Rw 40,44,47,50,53dB Rw 40,44,47,50,53,58dB Rw
Weight Approx 33-40kg/sq M Approx 43-50kg/sq M Approx 63-70kg/sq M



Sliding partition walls details

1. Change the room space flexibly.

2. Heavy track loading capacity make sure the safety of Partition.

3. Precise welding between separate rail can avoid repairing and maintenances in high probability.

4. Davao sliding partition walls retract and push easily, only one person can handle the moving job.

5. Wide application: can be used in office place, commercial place, exhibition place, hospital place, etc.
