Theater Folding Partition Walls Aluminum Track Wooden Gypsum Board Wall Partition

Price Negotiable
Price: 60-101 USD per square meter
MOQ: 10pcs
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Brand: EBUNGE
Product Description

Folding partition walls wooden india gypsum board wall partition sri lanka

Description:

Folding partition wall can separate the space speedy and conveniently.There is top hung system without the need for a floor track.Conference room soundproof wall partition is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.

Around the panel, there is sound insulation rubber, it can help to insulate the sound entering.Soundproof movable partition wall is hanging on the aluminum track, assembled with muti direction wheels.

Technical parameters:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

BUNGE's double,corrosion-resistant aluminum track systems are easy to install and easier to maintain.Extruding enables each section to have a uniform shape for superior end-to-end alignment.Each capacity-certified track is of extruded architectural grade clear anodized 6063-T5 aluminum.

To seal the corner,BUNGE gets its own design about specially developed conically shaped corner pieces that fit closely together,with high density,strong collision,is not easily deformed even at temperature -100℃. Compared with other same industry manufacturers,BUNGE has great superiority in both sealing and noise insulation factor for its products.

The quality of our all products is strictly controlled,only the superior raw material will be used.These are what we always concerned with,please rest assured for our constantly strive for excellence.

Manufacturer based

We are a professional comprehensive office glass partition Manufacturer in Guangzhou, China, we make sure to offer the best solutions of space flexible.

Our normal packing for movable partition wall is carton package, MDF batten on four section sides ,foam board on both front face.
