Machine manufacturers Low Noise Mini Blister Packaging Machinery Blister Pack Machines With CE Certificate
Machine manufacturers Low Noise mini blister packaging machine with CE certificate
Introduction:
Blister Packing Machine DPP-140A is small and suitable for the blister packaging of capsules, tablets (irregular tablets) and pills, etc., for small batch production.
- small volume
- High quality
- low energy consumption
Performance and characteristics:
- Pulling length can be adjusted. Mold is fixed by located groove so that It’s easy to change mold.
- The machine heats the PVC through heated board and forms by compressed air frothing.
- It adopts the interface of human-machine and PLC control system
- Mould and feeder can be designed according to customer’s requirement
- Functions for cutting line embossing, batch number embossing and wasted packaging material rewinding.
- Adopt Step motor for precise controlling the pulling length and saving packing material.
- The heating mold will automatically separate when the machine stops, which can protect the packing material from heated mould.
TECHNICAL PARAMETER
|
Item Model |
DPP-350A |
DPP-250A |
DPP-140A |
|
|
Cutting Frequency (ideal sizes:80*57mm) |
15-45 cutting/min |
15-45 cutting/min |
15-45 cutting/min |
|
|
Max. Forming Area and Depth |
350×130×15 |
250×120×15 |
140×110×15 |
|
|
Adjustable Scope of Travel(mm) |
30-140mm |
30-130mm |
30-120mm |
|
|
Packaging material (I.D.Φ75) |
PVC(mm) |
(0.15-0.6) ×350×(Φ400) |
(0.15-0.4) ×260×(Φ400) |
(0.15-0.4) ×160×(Φ350) |
|
PTP(mm) |
(0.02-0.15) ×350×(Φ400) |
(0.02-0.15) ×260×(Φ400) |
(0.02-0.15) ×160×(Φ350) |
|
|
Paper(mm) |
(50-100)g/㎡ ×350×(Φ400) |
(50-100)g/㎡ ×260×(Φ400) |
(50-100)g/㎡ ×160×(Φ350) |
|
|
Power |
380V 50Hz 9.5kw |
380V 50Hz 8kw |
380V 50Hz 5.5kw |
|
|
Air compression (Don't Provide) |
0.6-0.8Mpa ≥0.6m³/min |
0.6-0.8Mpa ≥0.45m³/min |
0.6-0.8Mpa ≥0.4m³/min |
|
|
Recycle water or circulating water consumption |
60-100L/h |
40-80L/h |
40-80L/h |
|
|
Overall Dimension(L*W*H)(including foundation) |
3650×850×1700 |
2900×750×1600 |
2400×650×1450 |
|
|
Dimension of Each Part |
1850×850×1700(front) |
1500×750×1600(front) |
1350×650×1250(front) |
|
|
1800×850×1650(back) |
1400×750×1450(back) |
1050×650×1450(back) |
||
|
Weight |
About 2000kg |
About 1200kg |
About 800kg |
|
This machine can be used in small pharmacy factory, dosage room of hospital , institute laboratory , health care product plat, food industry.
