Galvanized Steel Floor Deck Roll Forming Machine 28 Stations 0.75 - 1.2mm Thickness
Price:
negotiable
MOQ:
1set
Delivery Time:
60-80 days
Brand:
SUSSMAN
Product Description
PLC Control Roll Forming Equipment For Floor Decking Panel 7.5KW 380V 50Hz
all parts with the floor decking roll forming machines manufacturer
| Roll forming machine | 1 set |
| Uncoiler system | 1 set(Manual, hydraulic decoiler can be provided) |
| Entry Beach | 2 set |
| Mould | 3 set(Adjustable ) |
| Control Panel | 2 set |
| Hydraulic Station | 1 set |
| Table | 2 set(adjustable) |
| Punching system | 1 set(Depend on your need) |
the parameters of floor decking roll forming machines manufacturer
| floor decking roll forming machines manufacturer Description | Introduction |
| Working efficiency | 8-12m/min |
| Thickness of Material | 1.2-1.5mm(can be changed according to customers need) |
| Width of material | According to customers need |
| Control system | PLC(The brand can be choose) |
| Uncoiler system | 5Ton Manual Operation(1250mm width) |
| Forming by rolling | 24 rows(According to the machine design) |
| Roller material | GCR15 Aluminium processing after quenchin HRC58-62°C,Chrome plated |
| Shaft and the diameter of axle | 45#Aluminium-processing ,diameter of axle=100mm |
| Main part power | 2*11kw |
| Hydraulic motor power | 5.5kw |
| Hydraulic pressure | 12Mpa |
| Scissor material | Cr12Mov, herd steel HRC 58-62°C |
| length tolerance | ±1.5mm |
| voltage | 380V, 50HZ,3 phase(adjustable by customer needs) |
| Frame form | Middle plate |
| Driving Method | Chain |
| Color | Yellow and blue(adjustable) |
| Size | length*Width*Height - 6.8*0.8*1.2m |
| weight | about 8.5T |
| Package | Nude package in 1*40GP container |
| Delivery date | 40 working days |
| Payment Method | 30% T/T in advance and balance 70% after inspection confirmation before shipment. |
| If you have your own drawing, please send it to us, we can design the machine, depend on your drawing. | |
Working Flow of Roll Forming Machine
De-coiler—→Level device —→Main roll forming machine—→Hydraulic cutting—→ Run out table
