25 T ISUZU 6x4 refrigerated truck transportation Original Japan Import Engine 360 HP
Price:
USD 50,000 ~ 78,000 / Unit
MOQ:
1 unit
Delivery Time:
15 ~ 20 working days
Brand:
SUNY
Product Description
25 T ISUZU 6x4 refrigerated truck transportation Original Japan Import Engine 360 HP
Thickness: FRP inside & outside of the van, polyurethane as the insulation.
Stainless steel, Q235A steel sheet or aluminum are all optional.
Refrigerators chosen from:
South korean Hanya, HuaSu.
American Thermoking, Carrier.
Chinese Xinfei, Kingbo, etc.
Temperature reaches from -5°C to -18°C
Total capacity: approx. 20000 KG ~ 25000 KG ~ Max .35000 KG
Other spares like hooks, bottom slot, shelves, extra doors, etc. are all optional.
| Products Technical Specification | ||||
| Brand-Series | ISUZU | |||
| Product Name | 6x4 Refrigerated truck | |||
| Fuel type | Diesel | |||
| Emission Standard | Euro 3 | |||
| Cabin | Half row , With A/C | |||
| Chassis standard configuration | ||||
| Chassis model | CYZ51Q | |||
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 9640*2540*3680 | ||
| Cargo body dimensions (L×W×H) | 7155*2310*2200 | |||
| Wheel base | 4595+1310 | |||
| Front / Rear track base | 1855 / 1855 | |||
| Front / Rear overhang | 1335 / 2355 | |||
| Weight data (kg) | G.V.W | 25000 | ||
| Curb weight (chassis) | 10100 | |||
| Max payload | 20000-25000 | |||
| Whole vehicle main performance |
Max. speed (km/h) | 90 | ||
| Max. slope of climb (%) | 30 | |||
| Engine | Model | 6WF1A | ||
| Maximum power | 265 KW / 360 HP | |||
| Number of cylinders | 6 | |||
| Displacement (lit) | 14.256 | |||
| Engine Manufacturer | Liuzhou Wuling Liu Power CO,.LTD | |||
| Gear box | Number of gears | 8 forward gears & 1 reverse | ||
| Axle | Front / Rear Load capacity(ton) | 8 / 13 | ||
| Suspension | Front / Rear Spring plate | 9/10 | ||
| Steering Wheel | left/right hand drive | LHD | ||
| Brake system | Service brake | Ail braking | ||
| Electric device | Voltage (V) | 24 | ||
| Tire & Quantity | 11.00R 20 & 10+1 | |||
| Cargo Body Standard Configuration | ||||
| Cargo Body Size | (L×W×H) mm | 7155*2310*2200 | ||
| Cargo Body Material | FRP inside & outside of the van, polyurethane as the insulation | |||
| Cargo body thickness | 80mm | |||
| Back Door | Single door | |||
| Side door | Optional | |||
| Refrigeration systems | Equipped with DT-500 | |||
| Temperature Range | Normal temperature,refrigeration temperature reached -18C to 0°C | |||
| Others |
Stainless Steel door frame, Stainless steel corrugated floor, Mark lamp at the four (4) corners f the body, Room lamp will be provided inside the cabin. |
|||
|
||||
