500mm 19.6 Inches Carbon Fiber Tubes Glossy Surface 3K Roll Wrapped 100% Pure
500mm (19.6 inches) Carbon Fiber Tubes Glossy Surface 3K Roll Wrapped 100% Pure
LIJIN carbon fiber tubes contain 100% carbon fiber imported from Japan. The surface is plain weave, glossy surface/ twill weave, and matte finishes without any glass fiber contents. High stiffness, high tensile strength, low weight, high chemical resistance, high-temperature tolerance, and low thermal expansion are also proof of LIJIN carbon fiber tubes. In the past few years, our carbon fiber tubes have been trusted and supported by many customers.
Product Description:
- Item Name: Full Carbon Fiber Tubes
- Dimension: 500MM in length / 420MM in length / 300MM in length, etc.
- Inner Diameter x Outer Diameter: 4X6MM 6X8MM 8X10MM 10X12MM 12X14MM 14X16MM 16x18MM 18x20MM 20X22MM 22X25MM 23X25MM 24X26MM 25X27MM 28X30MM 30X32MM 37X40MM, etc.
- Surface: 3K, Plain Weave, Glossy Surface/ Twill Weave, Matte Finish
- Features: Strength and Light Weight
Product Advantages:
1. High-Quality Carbon Fibers Material
The carbon fiber material we use is resin-impregnated woven cloth that is commonly referred to as “pre-preg.” It is made with high-quality carbon fibers combined with space industry-defined resin systems.
2. Beautiful and Quality Tubes
We use heated compression molding to cure the pre-preg material into round tubes.
3. Features
- High strength and stiffness with low weight
- Excellent fatigue resistance
- Dimensional stability: Low to Zero CTE (Coefficient of Thermal Expansion)
4. Widely Application
LIJIN offers a wide range of carbon fiber tubes for many different applications. Carbon fiber tubes are used in numerous applications like tactical ladders, trusses, beams, and more.
| Material | Carbon Fiber Tube |
| Shape | Round/Oval |
| Technology | Roll-wrapped or pultrusion |
| Dimension | The existing inner diameter of the mold is 4mm-50mm with a length of 1m. |
| Customizable size: The maximum diameter can be 200mm, the longest can be 3m. | |
| Surface | Black glossy/matte surface/painted |
| Glossy 3k weave/matte 3k weave | |
| Color metal wire weave | |
| Feature | lightweight, high strength |
| Working Temperature | Usually, -30-120 degrees, if special requirement, please let us know. |
| Place Of Origin | China |
| Function | Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products |
| Tolerance | Diameter Tolerance: +/-0.1mm |
| Length Tolerance | +/-1mm |
Our Service:
1. It ensures a year of quality assurance and 24-hour online customer service.
2. Protection of your sales area, ideas of design, and all your private information.
3. Request for samples is accepted.
4. Drilling and slotting are accepted.
5. We guarantee the products to be manufactured with the finest materials and mature technics.
All tubes can be repaired at no charge if returned to us, postage prepaid, within one year.
