24 Watt 110VAC RGB LED Wall Washer , Full Color Outdoor Wall Wash Lighting
24watt 110VAC input RGB LED Wall Washer Cree 110lm/W 80Ra with Built-in Drive
Description
Model No.: MS-WW-RGB-A
Rated Power: 8W/24W/36W
Input: AC110V/AC220V
Lens Angle: 10°/15°/25°/ 45°/ 15°x50°
Dimension(LxWxH): 3ft@1000mmx77mmx126mm
Light Source: RGB/R/G/B/W/Y
Control: DMX512/on-off
IP Grade: IP65
Specification
| Model No.: MS-WW-RGB-A(24W) | ||
| Electric Parameter |
Max.Power | 24W |
| LED Drive Current | 350mA | |
| Input Voltage | AC110V/AC220V | |
| Power Efficiency | >90% | |
| Environment Parameter |
Humidity | 0～85%RH |
| Storage Temp. | -40℃～+80℃ | |
| Operating Temp. | -25℃～ +50℃(-13°F ～ +122°F) | |
| Physical Parameter | Dimension | 1000mm(L)x77mm(W)x126mm(H) |
| Weight | 4kg | |
| Material | aluminum & tempered glass | |
| Housing Color | silver | |
| IP Grade | IP65 | |
| Optical Parameter |
LED Brand | CREE XPE |
| LED Unit Power | 1W | |
| LED Quanity | 24pcs | |
| Light Source | 8R8G8B/24R/24G/24B/24W/24Y | |
| Lens Angle | 10°/15°/25°/ 45°/ 15°x50° | |
| Life Time | 50,000hrs | |
| Controller | DMX512 / On-Off | |
Features
1. 110V/220VAC input with high power input
2. Simple cable connection for installation
3. Mono-color & RGB multi-color
4. IP65
Competitive Advantages
1) Input: 110V/220VAC 2) Good heat dissipation 3) High Lumens(100-110lm/w)
4) long-life span 5) Energy saving 6) Design special
Application
Waterfall, bulding outline, bridge, river,museum, etc.
