36 Watt Linear RGB LED Wall Washer Wall Wash Landscape Lighting Fixture
LED linear light 36watts outdoor landscape lighting fixture
Description
MS-WW-RGB-A have the high performance for outdoor building decoration.
The lights are With LEDLink lens, Cree led, Meanwell power supply and tempered glass to go for high performance and reliability.Maysee provides 3-year warranty and the best competitive technical solution accord with any special requirement from customers.
36w LED wall washer lights are the most popular model preferred by customers both the indoor and outdoor decorative wall washers, widely used for shopping mall, bridge, park and garden, etc.
Specification
| Model No.: MS-WW-RGB-A(36W) | ||
| Electric Parameter |
Power | 36W |
| LED Drive Current | 350mA | |
| Input Voltage | AC110-220/DC24V | |
| Power Efficiency | >90% | |
| Environment Parameter |
Humidity | 0～85%RH |
| Storage Temp. | -40℃～+80℃ | |
| Operating Temp. | -25℃～ +50℃(-13°F ～ +122°F) | |
| Physical Parameter | Dimension | 1000mmx54mm(W)x95mm(H) |
| Weight | 3.2kg | |
| Material | aluminum & tempered glass | |
| Housing Color | silver | |
| IP Grade | IP65 | |
| Optical Parameter |
LED Brand | CREE |
| LED Unit Power | 1W | |
| LED Quantity | 36pcs | |
| Light Source | 12R12G12B/36R/36G/36B/36W/36Y | |
| Lens Angle | 10°/15°/25°/ 45°/ 15°x50° | |
| White Color Temperature | Warm White(2700～3500K); Pure White(3500～5500K); Cool White(>5500K) |
|
| LED Wave Length | Red: 620 - 630nm; Green:520 - 525nm; Blue:465 - 470nm; Amber:590 - 595nm |
|
| Life Time | 50,000hrs | |
| Controller | DMX512 / On-Off | |
Application
1. Architectural lighting
2. Downlighting or uplighting for wall wash
3. Landscape lighting
4. Road and bridge lighting
5. Museum and gallery lighting
Features
1. Anodized aluminum housing & Cree leds
2. With110V/220VAC high-power input
3. Up to 50,000hrs long life-span
4. Easy for cable connection and installation layout
5. Both RGB & mono-color are available
6. IP65
