SANHUAN Steering 77 Passenger Aero Bus With Pneumatic Suspension
Aero Bus World Top 2 Manufacturer Reliable Quality Competitive Price 13m Length
Description:
1. Passenger doors on both sides
2. More mobility and flexibility on the apron
3. Competitive Price
Specification:
|
No. |
Particulars |
Specs |
|---|---|---|
|
1. |
Length × Width ×Height |
13650mm×2700mm×3178mm |
|
2. |
Bus body |
Low carbon alloy steel body with aluminum apron; |
|
3. |
Wheel base |
6670mm |
|
4. |
Passenger accommodation capacity |
Up to 77 passengers including thirteen (13) seats, in compliance with IATA specifications: four (4) Passengers per sqm |
|
5. |
Curb weight |
12250kgs |
|
6. |
Steering |
SANHUAN, 3401ZB3-001H |
|
7. |
Rear axle |
Specially manufactured high intensity curved axle |
|
8. |
Front tire (single tire) |
BRIDGESTONE, 12R22.5 |
|
9. |
Rear tire (twins) |
BRIDGESTONE, 9.5R17.5 |
|
10. |
Pneumatic suspension |
GOODYEAR, 270~340mm, 6 nr. pneumatic suspension |
|
Fuel tank volume |
(120 + 80)liter |
|
Anti-freeze fluid |
20 liter |
|
Engine lubrication system |
14.2 litter |
|
Gearbox lubrication system |
18 liter |
|
Main reduction gear of front axle and wheel rim reduction gear |
10 liter |
|
The varied height from passenger cabin floor sill to the ground level |
270mm~340mm subject to embarkation and/or disembarkation of passengers |
|
Minimum turning radius |
<13500mm |
|
Engine |
4-strok, DEUTZ diesel engine |
1. Set the brake system discharge device by following the instruction labeled;
2. The emergency cover on wheel cover should be sealed to prevent from waterproof;
