Plastic 10 / 100M GPON EPON 4 Ethernet Ports 2 FXS ports External Power
Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade. Support rich QinQ VLAN functions and IGMP Snooping multicast features.
Integrated line testing compliant with GR-909 on POTS.
Support EPON fiber transceiver,CATV Rx and RF output diagnostic monitoring, EPON fiber
Transmitter and RF receiver disable remotely.
Support 1 or 2 LLIDs.
Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
For small and medium-sized operators, VoIP services are customizable.
POTS Service Functions
1) Call protocol: SIP (IMS compatible), seamless compatible with all popular call agent.
2) Voice coding: ITU-T G.711/G.723.1(5.3K/6.3Kbit/s)/G.729, auto-negotiate with call agent.
3) Support high/low speed fax, bypass fax, and T38 fax.
4) Support RFC2833 and redundant RFC2833, difference rings, MD5 authentication, call forward, call waiting, hot-line call, 3 way conference and all kinds of value-added voice service.
5) IP addresses assignment: dynamic PPPoE/DHCP Client and static IP.
6) Support WEB, CLI, TR069.
7) Integrated OAM, XML,DHCP option 66 & 67 for auto configuration and firmware upgrade.
Data Service Functions
1) 1K MAC address table, 64 full range VLAN ID.
2) Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.
3) Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.
4) Integrated IEEE802.1p QoS with four level priority queues.
5) Support IPv4 IGMP snooping and IPv6 MLD snooping.
CATV Service Functions
1) Turn on/off RF output remotely.
2) RF level showed on PC Web real time.
