Product Information:

MF52 is a bead-type NTC (Negative Temperature Coefficient) thermistor, with its main parameters as follows:
Resistance parameters:
Nominal resistance (R@25℃): Ranging from 1kΩ to 100kΩ, with accuracy options of ±1%, ±2%, ±3%, ±5%, ±10%.
Material constant (B value): Common B values @(25℃/50℃) include 3380K, 3435K, 3550K, 3700K, 3950K, 3977K, 3990K, 4100K, etc.
Performance parameters:
Dissipation factor: ≥2.0mW/℃ (in still air).
Thermal time constant: ≤7 seconds (in still air).
Insulation resistance: Over 100MΩ (DC500V).
Operating temperature range: -50℃ to +150℃.
Appearance size and pin parameters:
Type A: Tinned copper wire or tinned copper-clad steel wire; maximum D is 2.2mm, maximum L1 is 3.5mm, minimum L2 is 25.0mm, d±0.05 is 0.35mm, F±0.5 is 1.8mm.
Type B: Enamelled wire; maximum D is 2.0mm, maximum L1 is 6.0mm, minimum L2 is confirmed by the user, L3±1, d±0.05 is 0.28mm.
Other parameters:
Rated power: ≤50mW.

Application:

Packing and Delivery:
