Bright Annealed Surface Stainless Steel Instrument Tubing / Tube American Standard
Price:
4300-9800USD/TON
MOQ:
negotiable
Delivery Time:
30 Days
Brand:
MTSCO
Product Description
Stainless Steel Instrument Tubing / Tube , Annealing Tube , America Standard
ASTM A213 Standard Chemical Composition :
| Elements | 304L(wt%) S30403 | 304(wt%) S30400 | 316L (wt%) S31603 | 316 (wt%) S31600 |
| (C) Carbon, max | 0.035 | 0.08 | 0.035 | 0.08 |
| (Mn) Manganese, max | 2 | 2 | 2 | 2 |
| (P) Phosphorus, max | 0.045 | 0.045 | 0.045 | 0.045 |
| (S) Sulfur, max | 0.03 | 0.03 | 0.03 | 0.03 |
| (Si) Silicon, max | 1 | 1 | 1 | 1 |
| (Ni) Nickel | 8.0 - 12.0 | 8.0 - 11.0 | 10.0 - 14.0 | 10.0 - 14.0 |
| (Cr) Chromium | 18.0 - 20.0 | 18.0 - 20.0 | 16.0 - 18.0 | 16.0 - 18.0 |
| (Mo) Molybdenum | N/A | N/A | 2.0 - 3.0 | 2.0 - 3.0 |
| (Fe) Iron | Bal. | Bal. | Bal. | Bal. |
| (Cu) Copper | N/A | N/A | N/A | N/A |
| (N) Nitrogen | N/A | N/A | N/A | N/A |
Applications :
1 . General service industries ( petroleum , food , chemical , paper , fertilizer , fabric , aviation and nuclear )
2 . Fluid , gas and oil transport
3 . Pressure and heat transmission
4 . Construction and ornament
5 . Boiler and heat exchangers
6 . Decorative usage ( road lamp facilities , bridge handrail , expressway railing , bus stop , airport and gymnasium ) Etc
EN10216-5 Standard :
| Steel Grade | Tensile Properties At Room Temperature | |||||
| Steel Name | Steel Number | Proof Strength | Tensile Strength | Elongation Amin (%) | ||
| Rp0,2 min | Rp1,0 min | Rm | ||||
| Mpa | Mpa | Mpa | l | t | ||
| X2CrNi19-11 | 1.4306 | 180 | 215 | 460 to 680 | 40 | 35 |
| X5CrNi18-10 | 1.4301 | 195 | 230 | 500 to 700 | 40 | 35 |
| X6CrNiTi18-10 | 1.4541 | 200 | 235 | 500 to 730 | 35 | 30 |
| X6CrNiNb18-10 | 1.4550 | 205 | 240 | 510 to 740 | 35 | 30 |
| X2CrNiMo17-12-2 | 1.4404 | 190 | 225 | 490 to 690 | 40 | 30 |
| X5CrNiMo17-12-2 | 1.4401 | 205 | 240 | 510 to 710 | 40 | 30 |
| X6CrNiMoTi17-12-2 | 1.4571 | 210 | 245 | 500 to 730 | 35 | 30 |
