EN10216-5 1.4301 / 1.4306 Stainless Steel Seamless Tube For Petroleum , Chemical Industry
EN10216-5 1.4301 / 1.4306 Stainless Steel Tube With Bright Annealed Surface
EN10216-5 Standard Chemical Composition :
| Steel Grade | C | Si | Mn | P | S | N | Cr | Cu | Mo | Nb | Ni | Ti | Others | |
| max | max | max | ||||||||||||
| Steel Name | Steel Number | |||||||||||||
| X2CrNi19-11 | 1.4306 | 0.03 | ≤1 | ≤2 | 0.04 | 0.015 | ≤0.11 | 18.00 - 20.00 | - | - | - | 8.00 - 10.00 | - | - |
| X5CrNi18-10 | 1.4301 | 0.07 | ≤1 | ≤2 | 0.04 | 0.015 | ≤0.11 | 17.00 - 19.50 | - | - | - | 8.00 - 10.50 | - | - |
| X6CrNiTi18-10 | 1.4541 | 0.08 | ≤1 | ≤2 | 0.04 | 0.015 | ≤0.11 | 17.00 - 19.00 | - | - | - | 9.00 - 12.00 | 5xC to 0.70 | - |
| X6CrNiNb18-10 | 1.4550 | 0.08 | ≤1 | ≤2 | 0.04 | 0.015 | - | 17.00 - 19.00 | - | - | 10xC to 1.00 | 9.00 - 12.00 | - | - |
| X2CrNiMo17-12-2 | 1.4404 | 0.03 | ≤1 | ≤2 | 0.04 | 0.015 | ≤0.11 | 16.50 - 18.50 | - | 2.00 - 2.50 | - | 10.00 - 13.00 | - | - |
| X5CrNiMo17-12-2 | 1.4401 | 0.07 | ≤1 | ≤2 | 0.04 | 0.015 | ≤0.11 | 16.50 - 18.50 | - | 2.00 - 2.50 | - | 10.00 - 13.00 | - | - |
| X6CrNiMoTi17-12-2 | 1.4571 | 0.08 | ≤1 | ≤2 | 0.04 | 0.015 | - | 16.50 - 18.50 | - | 2.00 - 2.50 | - | 10.50 - 13.50 | 5xC to 0.70 | - |
Grade: TP 304; TP304H; TP304L; TP316; TP316L; TP 321;TP321H; TP317L; TP310S; TP347H
Standard: ASTM A213, ASTM A 269, ASTM A 270,EN10216-5; ASTM B 622;ASTM B516;ASTM A789, etc
Size: OD:3.18-101.6mm
WT:0.5-20mm
Length: Max.12M
Advantage: Superior surface finish ,better mechanical property; more precise dimension; perfect inspection method and inspection equipment
Application: Boiler tube applies to petroleum,chemical industry,electric power,boiler,high temperature
resistant,low temperature resistant,corrosion resistant.The size can be made according
to the customers requirements.High pressure boiler pipe applies to container,petrochemical
and so on.Note:Generally,high pressure boiler pipe’s working pressure above 9.88Mpa and
working temperature between 450 to 650.
Package: Plastic in both ends, then packed in iron case
Test :
1 . Corrosion Test : Conducted only when specially requested by the client
2 . Chemical Analysis : Test done as per required quality standards
3 . Destructive / Mechanical Testing : Tensile / Hardness / Flattening / Flaring
4 . Eddy Current Testing : 100% or partial test
5 . Hydrostatic Testing : 100%
