S30908 / S31008 Precision Stainless Steel Tubing Cold Rolled For Structure And Machining
S30908 / S31008 Stainless Steel Precision Tubing Cold Rolled With Bright Annealed Surface
Product Description
| Outer Diameter | 3.18-101.6mm |
| Wall Thickness | 0.5-20mm |
| NPS | 1/8"-24" |
| Schedule | 5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S |
| Material Grade | 304/304L/316/316L/321/309S/310S, etc |
| Standard | ASTM A269, ASTM A312, etc |
| Application | used in Fluid and Gas Transport, Structure and Machining,etc |
| Certificates | ISO9001:2008, PED, BV |
| Process Method | Cold Drawn/ Cold Rolled |
| Surface Finish | Annealed/ Polished |
| Package | Woven bag for each piece, then packed in seaworthy wooden cases |
| Delivery Time | 20-60 Days after receiving the deposit (Normally according to the order quantity) |
| Price Item | FOB, CIF or as negotiation |
| Payment | T/T(30% in advance, 70% against the BL Copy) or as negotiation |
| Quality Requirement | Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable |
| Main Market | Europe, Middle East, Southeast Asia, South America, etc |
ASTM A213 / A213M Chemical Composition :
| Elements | TP310S(wt%) S31008 |
| (C) Carbon, max : | 0.08 |
| (Mn) Manganese, max : | 2 |
| (P) Phosphorus, max : | 0.045 |
| (S) Sulfur, max : | 0.03 |
| (Si) Silicon, max : | 1 |
| (Ni) Nickel : | 19.0 - 22.0 |
| (Cr) Chromium : | 24.0 - 26.0 |
| (Mo) Molybdenum : | … |
| (Fe) Iron : | … |
| (Cu) Copper : | … |
| (N) Nitrogen : | … |
Test :
1 . NTD ( Ultrasonic test , Eddy Current test )
2 . Mechanical Test ( Tension Test , Flaring Test , Flattening Test , Hardness Test , Hydraulic test )
3 . Metal Test ( Metallographic Analysis , Impact Test-High / low temperature )
4 . Chemical Analysis ( Photoelectric Emission Spectroscopic )
MTSCO has the most advanced technology — The floating plug drawing technology which are used in Korea , and equipped with the most environmentally process — Bright annealing process . So our bright annealed precision tube produce technology make us can produce 300 tons high precision tubes every months .
Main Market :
MTSCO tubes main market include Europe , Middle East , Southeast Asia , South America etc .
