73.0X7.01MM TP304L Stainless Steel Welded Pipe Annealed Pickling

Price Negotiable

Price: 2400-12000USD/TON

MOQ: negotiable

Delivery Time: 30 Days

Brand: MTSCO

Product Description

TP304L 73.0MM*7.01MM Annealed&Pickling Stainless Steel Welded Pipe

Stainless Steel Welded Pipe:

Welded industrial stainless steel pipe should be used in more low pressure, structural or ornamental applications, and welded is more cost-effective.

A major benefit of a welded stainless steel pipe is the price. Welded pipe on average is cheaper than seamless. Seamless has a limit on the range of possible sizes where welded does not.

Stainless Steel Welded Pipe Material :

American Standard	TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc
European Standard	1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc
German Standard	X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc

Stainless Steel Welded Pipe Chemical Composition:

Chemical Composition % Max
C	Mn	P	S	Si	Cr	Ni	Mo	N B	Nb	Ti
TP304	0.08	2	0.045	0.03	1	18.0-20.0	8.0-11.0	^	^	^.	^
TP304L	0.035	2	0.045	0.03	1	18.0-20.0	8.0-12.0	^	^	^	^
TP316	0.08	2	0.045	0.03	1	16.0-18.0	10.0-14.0	2.00-3.00	^	^	^
TP316L	0.035 D	2	0.045	0.03	1	16.0-18.0	10.0-15.0	2.00-3.00	^	^	^
TP321	0.08	2	0.045	0.03	1	17.0-19.0	9.0-12.0	^	^	^	5C -0.70
TP347	0.08	2	0.045	0.03	1	17.0-19.0	9.0-12.0			10C -1.10	^

Stainless Steel Welded Pipe Industry Advantage:

Industry & Advantage	Application	a) For fluid & gas transport
		b) Structure & machining etc
	Advantages	a) Advanced technology of cold draw machine
		b) Advanced annealing machine
		c) Better mechanical property
		d) More precise dimension
		e) Perfect inspection method and inspection equipment etc

Stainless Steel Welded Pipe Specifications :

DN	NPS(Inch)	D(mm)	SCH5S	SCH10S	SCH10	SCH20	SCH30	STD	SCH40	SCH60	SCH80	XS
300	12	323.9	3.96	4.57	-	6.35	8.38	9.53	10.31	14.27	17.48	12.7
350	14	355.6	3.96	4.78	6.35	7.92	9.53	9.53	11.13	15.09	19.05	12.7
400	16	406.4	4.19	4.78	6.35	7.92	9.53	9.53	12.7	16.66	21.44	12.7
450	18	457.2	4.19	4.78	6.35	7.92	11.13	9.53	14.27	19.05	23.83	12.7
500	20	508	4.78	5.54	6.35	9.53	12.7	9.53	15.09	20.62	26.19	12.7
550	22	559	4.78	5.54	6.35	9.53	12.7	9.53	-	22.23	28.58	12.7
600	24	610	5.54	6.35	6.35	9.53	14.27	9.53	17.48	24.61	30.96	12.7
650	26	660	-	-	7.92	12.7	-	9.53	-	-	-	12.7
700	28	711	-	-	7.92	12.7	15.88	9.53	-	-	-	12.7
750	30	762	6.35	7.92	7.92	12.7	15.88	9.53	-	-	-	12.7
800	32	813	-	-	7.92	12.7	15.88	9.53	17.48	-	-	12.7
850	34	864	-	-	7.92	12.7	15.88	9.53	17.48	-	-	12.7
900	36	914	-	-	7.92	12.7	15.88	9.53	19.05	-	-	12.7
950	38	965	-	-	-	-	-	9.53	-	-	-	12.7
1000	40	1016	-	-	-	-	-	9.53	-	-	-	12.7
1050	42	1067	-	-	-	-	-	9.53	-	-	-	12.7
1100	44	1118	-	-	-	-	-	9.53	-	-	-	12.7
1150	46	1168	-	-	-	-	-	9.53	-	-	-	12.7
1200	48	1219	-	-	-	-	-	9.53	-	-	-	12.7

Company Introduction

MTSCO established in 2006, during many years’ development, now becomes a large and professional industrial piping system provider,

serving customers from more than 100 countries and regions.

What products can MTSCO provide?



What materials can we provide?

Austenitic: 304/L/H/N,316/L/H/N/Ti,321/H,309/H,310S,347/H,317/L904L

Duplex steel: 31803,32205,32750,32760

Nickel Alloy:

UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230,

R30556

UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

UNS N04400, N05500

Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

Nickel: N4/UNS N02201, N6/UNS N02200
