Heavy Duty Stationary Scissors Lift Platform Good Performance Materials Handling Equipment
Heavy Duty Stationary Scissors Lift Platform , High Performance Outdoor Type 1500kg Capacity
Product Description
Stationary hydraulic industrial electric scissor lift platform is the special hydraulic lift used for conveying cargoes between building layers.
The product is mainly used for conveying cargoes up and down between workshops, warehouse and various working layers:lifting auto-mobiles between layers in stereo garage and understand garage.
Product hydraulic system has anti-falling and overloading safety productive devices, and all layers and lift working face can set operating buttons to realize multi-point control.
Usage:
1.Considering security problem, the platform generally is equipped with antiskid insulated plastic water groove boards,
easy to change.
2.Mobile hydraulic lift with artificial mobile hydraulic lift, electric portable hydraulic lift, the other with a hand pump,used for power failure.
3.Mobile and flexible, smooth lifting, easy operation, large capacity.
4.The series mobile hydraulic scissor lifting platform with a multi purpose, indoor and outdoor use can be widely used in railway stations,airports, bridges, inquiries, internal and external mechanical plant installation,equipment maintenance, construction and maintenance and so on.
Specifications:
| Model | LS1001 | LS2001 | LS4001 |
| Load capacity | 1000kg | 1500kg | 4000kg |
| Max. lift height | 900mm | 1000mm | 1050mm |
| Min. height of table | 205mm | 230mm | 240mm |
| Table size | 1300*820mm | 1300*850mm | 1700*1200mm |
| Service weight | 160kg | 235kg | 375kg |
| Base size | 1240*640mm | 1220*785mm | 1600*900mm |
| Rise time | 20-25 | 20-25 | 30-40 |
| Electrical source parameter | 380V/50Hz | 380V/50Hz | 380V/50Hz |
Feature:
1. Color : yellow, orange or as per customer request
2. Capacity: 4000kg, 1000kg and 2000kg are available
3. Table size: 1700*1200mm
4. Advanced Robot welding ensure high strength, good finish, no bubble in the welding.
5. With CE certifications, waiting for your order!
6. Power coating finish, reliable quality
7. Installed with safety bar device
8. With overload protection
9. High-strengh materials, sturdy structure.
Our advantages:
1) More than 22 years experience team in manufacturing, service.
2) With ISO certificates service and quality is before profit
3) Sample order is welcomed
4) CE/TUV, ISO certificates
5) Free maintenance design
6) Fast delivery time within 30days
Innovation design: details
1) High reliability, suitable for a variety of environments.
2) High-strength alloy steel carefully crafted, increased loading capacity.
3) Set the active safety valve to prevent overloading of operation.
4) Maintenance-free design, ensure security, reduce service cost.
